Low Failure PP Woven Bag Production Line , Pp Woven Sack Making Machine SBYZ-2500x10
Low Failure PP Woven Bag Production Line , Pp Woven Sack Making Machine SBYZ-2500x10
Low Failure PP Woven Bag Production Line , Pp Woven Sack Making Machine SBYZ-2500x10
Low Failure PP Woven Bag Production Line , Pp Woven Sack Making Machine SBYZ-2500x10
Specifications
Model Number :
SBYZ
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Depends on different model
Payment Terms :
L/C, T/T
Supply Ability :
4 sets / 90 days
Delivery Time :
90 days
Packaging Details :
Without package or wooden
Bag Type :
Plastic Woven Bag
Machine Type :
Bag Forming
Material :
Plastic
Shuttles :
10 pcs
Max. Speed :
80 rpm
Warp Tape :
2500 pcs
Description

Descriptions Of SBYZ-2500x10 :

  1. Products : Flexible intermediate bulk containers (FIBC's), flat container fabric (U-panel FIBC), tarpaulin, geo-textiles and other type woven fabric.
  2. Motor : Adopt Direct Synchronization Torque motor to the flat cam directly.
  3. Shuttle Unit : Adopt idler wheel form.
  4. Electronic Control System : Adopt European brand program processor.
  5. The whole machine parte and system provide good condition to make high quality fabric.
  6. Features : High efficiency, energy saving, consumption reduction, stable and easy operation, low failure, powerful, centralized control.
Main Technical Parameters
Model Unit SBYZ-2500x10
Number Of Shuttles pcs 10
Max. Revolutions rpm 80
Weft Insertion ppm 800
Working Width / Double Flat mm 1800-2250
Working Width / Double Flat (At Reduced Pick Rate) mm 2100-2250
Number Of Warp Tape pcs 2500
Warp / Weft Core Inside Diameter mm 35
Warp / Weft Core Length mm 218
Max. Warp Bobbin Diameter mm 160
Max. Weft Bobbin Diameter mm 115
Main Motor Power Kw 11
Warp Infeed Motor Rating Kw 0.25 x 4
Haul Off Motor Rating Kw 1.1
Winder Torque Motor Rating Nm 5
Max. Roll Diameter mm φ1200
Dimensions mm 17800 x 4000 x 4500
Weight T 10.8

'
