The unique technology ensures global uniform splicing and with its features and benefits:

1. Improved quality, efficiency (speed) and precision

2. Consistent, reliable splice results and superior belt appearance

3. Less shrinkage of fingers, providing stronger, flatter splices

4. No maintenance.

5.12″/24″/36″/48″/60″/72″/84″ available.

6. Voltage: 220V or 380V, if you need a special voltage please our sales.

On site benefits include:

1. Short cycle time, approx. 10 minutes or less depending on belt type

2. Lightweight components

3. No water or forced air cooling necessary

4. Less production downtime

5. Easy transport around the plant

Specifications:

Model: LY1800
Heating plate effective L*W : 1829 *130mm
Weight lower part : 32 kg
Weight upper part : 42 kg

Bumper bar:37kg
Naked weight : 76 kg
Naked Length : 2005 mm
Naked Overall Height: 225 mm
Naked Overall Width: 255mm
Max. pressure: 2Bar
Max. temperature : 200 ˚C
Dimensions for transport box: 2212 x 352 x300
Weight In transport box: 176 kg
Power: 7.6 Quality assurance:

I. Whole unit 12 months warranty

II. Adopt high quality imported parts :

1.High quality Eurotherm brand controller.Reliable and automatic Temperature Control with time control (in one meter, also you can set by yourself).

2. High quality SMC brand controller.Air pressure controller (set the air pressure and display the current pressure),

3. High quality heating plate from USA. fast and uniform,from 60 degree to 165 degree ONLY need 2’30” .
