EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port
Specifications
Brand Name :
ZIKUN
Model Number :
ZC-P1016E
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
5-15 work days
High Light :
EPON 16 Port OLT, Layer 3 16 Port OLT, V1600D16 Layer 3 OLT
Product Name :
Layer3 16 Ports EPON OLT
Dimension :
445mm×321mm×46mm (L×W×H)
Wavelength :
Tx1310nm, R x 1490nm
Power Supply :
AC 100~240 V, 50/60 Hz
Power Consumption :
≤85W
Description

ZIKUN EPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port

Product Description

ZC-P1016E EPON OLT is 1U height 19 inch rack mount products. The features of the OLT are small, convenient, flexible, easy to deploy, high performance. It is appropriate to be deployed in compact room environment. The OLTs can be used for “Triple-Play”, VPN, IP Camera, Enterprise LAN and ICT applications.

ZC-P1016E EPON OLT provides 16 EPON ports, 8GE copper RJ45 Ethernet ports and 4*GE(SFP)/4*10GE(SFP+). It has high reliability, high density and powerful switching and routing abilities. It is a new generation of broadband and multi-service access OLT devices oriented towards the service-integrated network.

ZIKUN EPON OLT ZC-P1016E
Small and Flexible | High Performance | Easy to DeployEPON 16 Port OLT Layer 3 Support Up To 1024 ONU 64 ONU Per PON Port

Technical Specifications

Parameter Specifications
PON standard EPON ITU-T G.984.x

PON interface

 16*GPON SFP Ports (Class C+), Receiving sensitivity: ≤ -30d Bm(Saturation Optical - 12d Bm). Power,Transmitting optical power: +3 ~ +7d BmTransmission distance: 20KM. Max splitting ratio1:128
Upstream 2.488G ,Downstream 1.244G
Wavelength Tx1310nm, R x 1490nm
Uplink 8*copper Ethernet ports 10/100/1000M auto-negotiation
4*GE(SFP)/ 4*10GE (SFP+) auto-detection
Layer 3 Support static route, RIP v1/v2, OSFP v2, ARP proxy
Management Ports 1*10/ 100BASE-T out-band port, 1*CONSOLE port
Management Mode SNMP, Telnet, CLI, WEB
VLAN Tag / Un-tag,VLAN transmission,QinQ
Operating condition Operating temp: -5 C~ +55C
Storing condition Storing temp: -40C ~ +85C
Humidity 5~90%(non-condensing)
Power consumption ≤85W
Dimension 445mm×321mm×46mm (L×W×H)
Net weight 5.25Kg
