FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT
Specifications
Brand Name :
ZiKUN
Model Number :
ZC-1008G
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
5-15 work days
Place of Origin :
China
Type :
EPON OLT
Use :
Enterprise
Pon port :
8 GPON ports
Distance :
20km
Product Name :
8-port EPON OLT
Application :
Fiber To Home
Max Splitting Ratio :
1:64
Rack Mount :
1U 19 Inch Standard Box
Description
FTTH FTTX Fiber Optic Zikun ZC-1008E 8-Port EPON GPON OLT
FTTH FTTX 8 Port EPON GPON OLT Zikun ZC-1008E Fiber Optic OLT

Roduct Description

ZC-1008E EPON OLT products are 1U height 19 inch rack mount products. The features of the OLT are small, convenient, flexible, easy to deploy, high performance. It is appropriate to be deployed in compact room environment. The OLTs can be used for “TriplePlay”, VPN, IP Camera, Enterprise LAN and ICT applications.

There are three OLT model in this series, include ZC-1004E, ZC-1008E and ZC-1016E.

ZC-1008E provides 8GE(copper) and 8SFP slots independent interface for uplink, and 8*EPON OLT ports for downlink. It can be supported up to 128 ONUs under 1:64 splitter ratio.

Technical Specifications
Item ZC-1008E
Chassis Rack 1U 19 inch standard box

1000M
Uplink Port

 QTY 16
Copper 8*10/100/1000M auto-negotiation
SFP
(independent)		 8*SFP Or 4*SFP and SFP+ slots (SFP+ is 10GE port
EPON Port QTY 8
Physical Interface SFP Slots
Connector Type 1000BASE-PX20+
Max splitting ratio 1:64
Management Ports 1*10/100BASE-T out-band port, 1*CONSOLE port
PON Port Specification Transmission Distance 20KM
EPON port speed Symmetrical 1.25Gbps
Wavelength TX 1490nm, RX 1310nm
Connector SC/PC
Fiber Type 9/125μm SMF
TX Power +2~+7dBm
Rx Sensitivity -27dBm
Saturation Optical Power -6dBm
