Specifications
Brand Name :
ZIKUN
Model Number :
ZC-P1016G
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
5-15 work days
PON standard :
GPON ITU-T G.984.x
Management Ports :
1*10/ 100BASE-T out-band port, 1*CONSOLE port
Dimension :
445mm×321mm×46mm (L×W×H)
Management Mode :
SNMP, Telnet, CLI, WEB
Operating temp :
-5 C~ +55C
PON interface :
16*GPON SFP Ports (Class C+)
Description

ZIKUN GPON OLT 16 Port Compatible With HUAWEI ZTE ONU 8GE SFP 10GE SFP+

Product Overview

ZC-P1016G is a small-capacity cassette GPON OLT, meeting the requirements of ITU-T G.984/G.988 and relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability and the complete security function. It can satisfy long-distance optical fiber access requirement on account of its excellent management, maintenance and monitoring capability, abundant service features and flexible network mode. GPON OLT 16PON can be used with NGBNVIEW network management system so as to provide users with the comprehensive access and perfect solution.

ZC- 1016G GPON OLT provides 16 GPON ports, 8GE copper RJ45 Ethernet ports and 4*GE(SFP)/4*10GE(SFP+). The height is only 1U for easy installation and space saving. GPON OLT 16PON is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things, etc.

Cassette 16 Port GPON OLT Compatible With HUAWEI ZTE ONU 8GE SFP 10GE SFP+

Features

  • 1U 19-inch box GPON OLT with 16 PON ports
  • Comply with ITU-T G984 / G.988 standard
  • L3 function, support for static routing, RIP v1 / v2, OSFP v2, ARP agent
  • Tcont DBA, Gemport traffic
  • QoS based on port, VID, TOS, and MAC addresses
  • Support for VLAN Tag / UnTag, VLAN transmission, QinQ
  • Support for IGMP listening, 256 IP multicast groups, IGMP agent
  • Support for 802. 1D and 802. 1W
  • Support for static LACP
  • Professional design to prevent system failure and keep the system stable
  • Supports port-based rate restriction and bandwidth control
  • Support for data encryption, multicast, port VLAN, separation, RSTP, etc
  • Support for dynamic bandwidth allocation (DBA)
  • Support for ONU automatic discovery / link detection / software remote upgrade
  • Support for ONT automatic discovery, automatic configuration
  • Support for the ONT firmware can be automatically upgraded to download the ONT firmware to the OLT from the web / tftp / ftp
  • Support for SNMP, telnet, CLI, OMCI / OAM, and Web management
  • Support for ACL and SNMP, flexible configuration of package filters
  • Support the broadcast storm resistance function
  • Firewall function
  • Support for remote software upgrades
  • Support the power-off alarm function, to facilitate the detection of link problems
  • Support industrial temperature

Technical Specifications

Parameter Specifications
PON standard GPON ITU-T G.984.x,G.988

PON interface

 16*GPON SFP Ports , Receiving sensitivity: ≤ -30d Bm(Saturation Optical - 12d Bm). Power,Transmitting optical power: +3 ~ +7d BmTransmission distance: 20KM. Max splitting ratio1:128
Upstream 2.488G ,Downstream 1.244G
Wavelength Tx1490nm, Rx 1310nm
Uplink 8*copper Ethernet ports 10/100/1000M auto-negotiation
4*GE(SFP)/ 10GE (SFP+) auto-detection
Layer 3 Support static route, RIP v1/v2, OSFP v2, ARP proxy
MAC table 32K
Management Ports 1*10/ 100BASE-T out-band port, 1*CONSOLE port
Management Mode SNMP, Telnet, CLI, WEB
VLAN Tag / Un-tag,VLAN transmission,QinQ
Operating condition Operating temp: -5 C~ +55C
Storing condition Storing temp: -40C ~ +85C
Humidity 5~90%(non-condensing)
Power consumption AC100~240V, 47/63Hz(DC:-48V Option)
Power consumption ≤85W
Dimension 445mm×321mm×46mm (L×W×H)
Net weight 5.25Kg
