IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch
Specifications
Brand Name :
ZIKUN
Model Number :
ZC-S2012G
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
5-15 work days
Ports :
12
Switching capacity :
20G
Packet forwarding rate :
14.88Mpps
Monomode optical fiber :
20/40/60/80/100KM
Operating temperature :
-40℃~+85℃
Dimensions（mm） :
143X105X53
Input voltage DC(V) :
12-58
Description

ZIKUN Gigabit Managed Ethernet Industrial Poe Switch 12 Port Din Rail For Ip Camera Dual Dc Input

ZC-S2012G is an industrial grade gigabit PoE switch designed for industrial environment. 10 Gigabit adaptive Ethernet interfaces are provided. It provides rich and intelligent management function,supports management via Web interface. There are remote PoE power restart function. when the load equipment fails and crashes, the equipment can be restarted through remote operation (Web-UI).

IP Camera Gigabit Industrial Managed Poe Switch 12 Port Din Rail Ethernet Switch

Model Feature

Model ZC-S2006G ZC-S2010TG ZC-S2010G ZC-S2012G
Gigabit optical port(GE SFP) 2 1 2 2
Gigabit electrical por(GE RJ-45) 4 9 8 10
Input voltage DC(V) 12-58 12-58 12-58 12-58
Power consumption(W) <6 <6 <6 <6
Weight(kg) 0.5 0.5 0.5 0.58
Dimensions(mm) 143X105X53

Specifications

Provider Mode Ports
Power interface Phoenix terminal
LED Indicators PWR,SYS,Optical port indication
Cable type&Transmission distance
Twisted-pair 0-100m(CAT5e,CAT6)
Monomode optical fiber 20/40/60/80/100KM
Multimode optical fiber 550m
Electrical Specifications
input voltage DC12-58V
Layer 2 Switching
Switching capacity 12G
Packet forwarding rate

14.88Mpps
MAC address table 4K
Buffer 1M
Forwarding delay <10us
MDX/MIDX Support
Flow control Support
Jumbo Frame Support 9.6Kbytes
Environment Condition
Operating temperature -40℃~+85℃
Storage/transport temperature -40℃~+85℃
Relative humidity 5%~95% non-condensing
Thermal methods Fanless design, natural heat dissipation
Mechanical Dimensions
Installation Method Clamp rail installation, hanging ear installation
EMC&INGRESS PROTECTION
IP Level IP40
Surge protection of Power IEC 61000-4-5 Level X(6KV/4KV)(8/20us)
Surge protection of Ethernet port IEC 61000-4-5 Level 4(4KV/4KV)(10/700us)
ESD IEC 61000-4-2 Level 4 (8K/15K)
Authentication
Authentication Ministry of Public Security,CCC/CE/FCC/RoHS
Accessories
Accessories Equipment, terminals, certificate, manual, power adapter (optional)
