XSG PON ONU Optical Network Unit 10GE 1GE 2VOIP XG PON GPON Fiber Optical ONU
XSG PON ONU Optical Network Unit 10GE 1GE 2VOIP XG PON GPON Fiber Optical ONU
Specifications
Brand Name :
ZIKUN
Model Number :
ZC-512N
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
5-15 work days
Type :
XGS-PON
Optical connector :
SC/APC
User Network Interface :
1*10GE+1GE+2VoIP(option)
Dimensions ( W x Dx H) :
17.2CM*11.5CM*4CM
Weight :
About 400g
System power supply :
12V DC, 1A
Receiving Sensitivity :
-28dBm
Overload optical power :
-8 dBm
Description

ZIKUN GPON ONT 10GE XSG-PON ONU 1GE 2VOIP Fibers Optical XG-PON​

Description

ZIKUN ZC-512N offers 1 GE+1 10GE+2 POTS(1 GE ports, 1 10GE port,2 POTS ports). It is an XGS-PON routing-type ONT in the all-optical access solution.The high forwarding performance ensures the user experience of voice, data and HD video services, and provides customers with an ideal all-optical access solution and future-oriented service support capability.

Product Specification

GPON interface(NNI):1 x XGS-PON interface
Optical port CLass N2 optical system
Optical connector SC/APC
Receiving Sensitivity -28dBm
Overload optical power -8 dBm
Transmitting Optical Power 0.5~5dBm
Transmit rate 9.953Gbit/s downstream; 9.953Gbps upstream
Wavelength Receiving(DOWN):1577nm；Transmitting(UP):1270nm
Authentication SN/ Password/LOID /LOID+Password authentication
User Network Interface(UNI):1*10GE+1GE+2VoIP(option)

XSG PON ONU Optical Network Unit 10GE 1GE 2VOIP XG PON GPON Fiber Optical ONU

Physical Performance

Dimensions ( W x Dx H) 17.2CM*11.5CM*4CM
Weight About 400g
Working temperature 0°C ~ 45°C
Working humidity 5% RH to 95% RH (non-condensing)
Power adapter input 100–240 V AC, 50 / 60 Hz
System power supply 12V DC, 1 A
Power consumption <10W
