Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
KLSK
Model Number :
WT-602
Certification :
CE
Packaging Details :
Standard exporting package-Carton box
MOQ :
1PC
Price :
$1,200.00/pieces
Warranty :
1 years
Type :
Dust analyzer
Customized support :
OEM
Working wavelength :
650nm
Product name :
Dust Monitoring Equipment
Gas analyzer principle :
Scattered light backward
Application :
Online Stack Dust Monitor
Power :
24VDC+/-10%
Work temperature :
-40 ℃-+50 ℃
Measure Range :
0~200mg/m3, 0~10g/m3
Signal output :
(4-20) mA
Response time :
≤ 10s
Stock :
1PC
Description

WT602 Series Continuous Gas Monitoring System Industrial Waste Gas and Smoke Dust Meter

>>> Working Principle

WT602B series products use the principle of laser backscatter to complete the measurement of flue dust concentration. The embedded high stable laser signal source passes through the flue and irradiates the smoke particles. The irradiated smoke particles will reflect the laser signal, and the reflected signal intensity changes positively with the smoke concentration. The concentration of flue dust can be calculated by a specific algorithm.

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Product Description

Technical Specification

Parameters

WT602

Principle

Laser backscatter

Working wavelength

650nm

Zero drift

±2%F.S./24h

Range drift

±2%F.S./24h

Indication error

±15%

Response time

≤ 10s

Diameter of flue

(1-15)m

Operating temperature

(-40~+65) ºC

Flue temperature

<200ºC

Flue pressure

<1Kpa

Signal output

(4-20) mA

Power supply

DC 24V ± 10%

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Product Catalogue

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust MeterOnline Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Company Information

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

FAQ

Q1: Are you a trading company or manufacturer ?

A1: We aremanufacturer.

Q2: What about the payment method?

A2: T/T, Paypal, Western Union, L/C is available

Q3: Does your company accept customization?

A3: We do customizing service for customers.

Q4: What about the Shipment?

A4: We’ll choose proper transportation mode based on the weight of goods, usually arrange shipment by air express such as DHL,FEDEX,TNT or UPS.

Q5: What about after-sale service?

A5:12 months warranty for all kinds of products.
