Specifications
Warranty :
5years
Free installation service :
NO
Place of Origin :
Guangdong, China
Brand Name :
Haisic
Model Number :
HS-BG-9.5KWH
Application :
Home
Solar Panel Type :
Monocrystalline Silicon, Monocrystalline Silicon
Battery Type :
Lithium Ion
Controller Type :
MPPT
Mounting Type :
BIPV Mounting
Load Power (W) :
8KW
Output Voltage (V) :
220V,230V,240
Output Frequency :
50Hz±0.3Hz
Work Time (h) :
24H
Certificate :
NRS,IEC 62109-1/-2IEC 61000-6-1IEC61000-6-3
Pre-sales project design :
Y
Output voltage waveform :
Pure sine wave
Inverter :
8kW Hybrid Inverter
Controller :
MPPT Solar Charge Controller
Battery :
9.5kWh lifepo4 battery
Accessories :
Crimping Pliers
AC output :
220/230/240V
Protection :
IP65
OEM/ODM :
Accepatable
Load :
8kW
Packaging Details :
Packing in thicker carton
Port :
shenzhen
Supply Ability :
1000 Piece/Pieces per Month
MOQ :
5000 watts
Price :
$0.60/watts 5000-199999 watts
Description
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
Product Description
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
Specification
Energy storage battery parameters
Rated Voltage（V）
51.2
Rated Capacity（Ah）
186
Rated Energy（Wh）
9523
Operation Parameter
Voltage Range（V）
44.8-56
Charge Voltage Range（V）
55.2-56
Cut-off Voltage（V）
44.8
Recommend Charge Current（A）
100
Max Charge Current（A）
166
Max Discharge Current（A）
166
Physical Parameter
Dimension：L*W*H（mm）
457*163*760
Weight（kg）
70
Communication Port
RS485，CAN
Display
LED+LCD
Terminal
Plug-in
Compatible inverter
Growatt,Goodwe,DEYE,SRNE, Luxpower, Megarevo
Environment Parameter
Humidity（%）
5-95% RH
Charge Temperature Range（℃）
0-45
Discharge Temperature Range（℃）
-20-60
Storage Temperature Range（℃）
-20-45
Service Life
Cycle Life
＞6000 （0.5C@ 25℃，60% DOD）
Certification
Safety & Certification
CE，EMC，TUV（IEC62619），UL1973
Transportation
UN38.3
Hubrid Inverter parameters：
Model
R8KL1
Input (PV)
Max.power(kW)
12
Max. DC voltage(V)
500
MPPT voltagerange(V)
120~500
Max.input current of single MPPT(A)
12
MAX. short circuit current(A)
15
AC output
Rated output power(kVA)
8
Max.output power(kVA)
8.8
Max.output current(A)
38.3
Ac output voltage(V)
220,230,240
Frequency(Hz)
50/60 (45~55,55~65)
PF
0.8lagging-0.8leading
THDi
＜2%
Battery

Nominal voltage (V)
48
Battery voltage range(V)
40~60
Max. charge/discharge current(A)
190/190
Battery type
lithium /Lead-acid
Charging strategy for Li-lon battery
Self-adaption to BMS
EPS output

Rated power (kVA)
8
Rated output voltage(V)
220,230 ,240
THDu
＜2%
Rated frequency(Hz)
50/60
Protection
Grounding detection
YES
Arc fault protection
optional
lsland protection
YES
Battery reverse polarity
YES
Insulation resistor detection
YES
Residual current monitoring unit
YES
Output over current protection
YES
Back-up output short protection
YES
Terminal temperature detection
YES
Output over voltage/under voltage protection
YES
General data

Europe efficiency(PV)
≥97.8%
MAX battery to load efficiency
≥97.2%
Ingress protection
IP65
Noise emission(dB)
＜38
Operation temperature
-25C~60C
Cooling
FAN Cooling
Relative humidity
0-95%(non-condensing)
Altitude
2000m(>2000 Derating)
Dimensions W*D*H(mm)
430*220*710mm
Weight(kg)
41
Display
LCD，Touch panel (optinal)
Communication with BMS/meter/EMS
RS485，CAN
Communication interface
RS485,WLAN,4G(optional)
Self-consumption at night
< 2.5 W (with battery enabling < 5 W)
Certificates
South Africa NRSIEC 62109-1/-2IEC 61000-6-1 IEC 61000-6-3
Packing & Delivery
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
Packing in thicker carton
Company Profile
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
5kw 10kw 15kw Solar Energy System Home Hybrid Solar Power System Complete Kit Shenzhen
Founded in 2011, Shenzhen Haisic Technology Co., Ltd. is a national high-tech enterprise dedicated to the research and development, production and sales of lithium batteries like lithium polymer battery, lithium ion battery and LiFePO4 battery. Deeply engaged in this field for more than 10 years, Haisic Technology has accumulated profound experience in R&D, innovation, quality control and management. Our products are used in home energy storage, industrial energy storage, commercial energy, power communication, medical electronics, security communications, transportation and logistics, new energy power, smart home and other related fields. We have owned our own production base covering more than 11,000 square meters located in Dapeng district of Shenzhen with ISO9001, ISO14001, ISO45001 and Amfori BSCI, and our products are with CE, FCC, TUV-UL2054, CQC, RoHs, PSE, MSDS, UN38.3 certificates.We've already provided safe, stable, environmentally friendly, high-quality products and professional OEM/ODM services to customers in more than 60 countries and regions.
