10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Specifications
Warranty :
5years, 5years
Free installation service :
NO
Place of Origin :
Guangdong, China
Brand Name :
Haisic
Model Number :
HS-GS-10.5KWH
Application :
Home, Solar Power System Home
Solar Panel Type :
Monocrystalline Silicon
Battery Type :
Lithium Ion
Controller Type :
MPPT
Mounting Type :
BIPV Mounting
Load Power (W) :
10KW
Output Voltage (V) :
220V,230V,240
Output Frequency :
50HZ/60HZ
Work Time (h) :
24Hours
Certificate :
CE,CETL,ROHS,FC
Pre-sales project design :
Y
Product name :
Hybrid Solar System
Battery :
10kwh lifepo4 battery
Solar panel :
Monocrystalline Solar Panel
Inverter :
3L/N/PE
Keyword :
Photovoltaic Solar Energy System
Type :
Hybrid System AC
Specification :
Storage Solar System
Protection :
IP65
Packaging Details :
Box packing
Supply Ability :
1000 Piece/Pieces per Month
MOQ :
10000 watts
Price :
$0.69/watts 10000-99999 watts
Description
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Product Description
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Inverter features.
Safe & reliable Complete functional protection measures. Friendly & flexible LCD or touch panel are optional: Support diesel generator connection; support the parallel function: .4 MPPT trackers; Intelligent & efficient Max.charging/discharging current up to 250A Multiple working modes are optional: Support WIFI.GPRS.4GAPP
Solar panel parameters
Maximum Power: 425W Operating Voltage at Maximum Power:40.80V Operating Current at Maximum Power:10.42A Open Circuit Voltage:48.20V Short Circuit Current:11.12A Module Efficiency:19.2% Size: 2108x1048x35mm Weight: 25Kg Based on effective light duration of about 3.5 hours Solar panel rated output power:3.4KW Suitable for daily power consumption : <11.9KWH
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Specification
Energy storage battery parameters
Model
HS-GS5000W
Basic Parameter
Rated Voltage（V）
51.2
Rated Capacity（Ah）
100
Rated Energy（Wh）
5120
Operation Parameter
Voltage Range（V）
44.8-56
Charge Voltage Range（V）
55.2-56
Cut-off Voltage（V）
44.8
Recommend Charge Current（A）
50
Max Charge Current（A）
100
Max Discharge Current（A）
100
Physical Parameter
Dimension：L*W*H（mm）
470*452*160
Weight（kg）
46
Communication Port
RS485，CAN
Display
LED+LCD
Terminal
Plug-in
Compatible inverter
Growatt,Goodwe,DEYE,SRNE, Luxpower, Megarevo
Environment Parameter
Humidity（%）
5-95% RH
Charge Temperature Range（℃）
0-45
Discharge Temperature Range（℃）
-20-60
Storage Temperature Range（℃）
-20-45
Service Life
Cycle Life
＞6000 （0.5C@ 25℃，80% DOD）
Certification
Safety & Certification
CE，EMC，TUV（IEC62619），UL1973
Transportation
UN38.3
Hubrid Inverter parameters：
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Packing & Delivery
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
Packing in thicker carton
Company Profile
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
10kw Photovoltaic Solar Energy System with Akku Solar Battery Sustainable Home Energy
FAQ

1.Who are we?
We are direct factory, and manufacturer for R&D, production of lithium battery such as LifePO4 battery packs, solar energy storage batteries, solar portable power stations/generators and solar powerwalls. Found in 2011. we have more than 10 years' experience in this field.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.What payment terms can we do ?
The payment term will be 30%T/T for deposit and the balance before shipment.

4. What is the delivery time? What is your standard packing？
Sample is in 15days. Bulk order usually deliver in 30-35 days, but could be changed according to the quantity or other

5. What things does the package include？
2pc * 5kwh rack mounted storage LFP backup battery
1pc * 8000watts off-grid 5kw hybrid inverter 10pcs * Monocrystalline solar panles
3pcs * user manuals
5groups * installation holders
1bag * wiring and connection accessories
