Specifications
Brand Name :
Roadragon
Model Number :
TK801F
Certification :
CE,FCC,ROHS,ISO9000
Place of Origin :
China
MOQ :
1
Price :
Neogatiation
Payment Terms :
Paypal,HSBC,, Western Union, T/T, L/C
Supply Ability :
200000pieces per month
Delivery Time :
1-3 work days after payment
Packaging Details :
Box:12cmX6.5cmX7.5cm
Model :
mini gps tracker for car
Chip :
MTK MT2503
Battery :
400mAh
Color :
Red Black White
Time display :
LED indicator light
GSM/GPS Antenna :
Built-in design
SOS panic button :
Support
Size :
40X12mm
Description

Kids Location Mini Portable GPS Tracker GPRS Android Waterproof GPS Device

Brief Introduce:

A GPS tracking unit is a device, normally carried by a moving vehicle or person, that uses the Global Positioning System to determine and track its precise location, and hence that of its carrier, at intervals. The recorded location data can be stored within the tracking unit, or it may be transmitted to a central location database, or Internet-connected computer, using a cellular (GPRS or SMS), radio, or satellite modem embedded in the unit. This allows the asset's location to be displayed against a map backdrop either in real time or when analysing the track later, using GPS tracking software. Data tracking software is available for smartphones with GPS capability.


Function:

Structure parts
ID design Fashion
Whole machine size 40X12mm
Weight 25G
Button Power button/SOS button
Time display LED indicator light
gps antenna High sensitive ceramics active antenna
GSM antenna Four frenquency PIFA antenna
Hardware parts
Chip MTK MT2503
GPRS Class12
GPS signal L1,1575.42MHz C/A
GPS chip receive sensitivity Tracking sensitivity:-165dBm,capture sensitivity:-148dBm
Minimum standby current Less than 0.5 mA
Average standby current Less than 2.5 mA
Average working current About 55mA
GPS channel number 22 channels
Test and certification Can pass 3C and CE certification
G-senser Supported
MIC Supported


Function:

1, GPS + BD + WIFI + LBS Multiple Mode Positioning: The device can automatically recognize the positioning network and switch the positioning mode automatically too, indoors using LBS positioning mode while outdoors GPS positioning mode.

2, Phone Call: Besides serving as a GPS tracker, the device can also work as a mobile phone to make phone calls!

3, SOS Alarm(SOS Emergency Call): When the user encounter danger(like kidnapping or tumbling for person; theft for objectives/valuables; for lost pets and etc), the user can press the SOS button to make an emergency phone call to the SOS number asking for help.

4, Electronic Fence Alarm(Geo-fence ): You can set a safe area( the device owner as center) to keep the owner(such as your kids or pets) inside the area, when the device owner gets out of the safe area, the device will automatically raise an alarm in your phone application.

Feature:

1, Appearance: The tiny delicate design makes it lightweight & lightweight ; the special material processing craft makes it super good to feel and pleasant to the eye.

2, Multiple applications: For kids, elders, pets, vehicles, valuables, luggage and etc.

3, The Application is applicable to both of Android and IOS system, we offer lifetime application and platform service for free! Support will be provided in case client needs manager account to mange the devices, and sub-manager account can be created level by level downward!

4, Long standby time: There are 3 working time interval for the device positioning data uploading : 1 min, 10 min, 1 hour. Interval shorter, battery life longer. Interval 1 min, battery lasting about 1 day; 10 min, battery lasting about 2-3 days; 1 hour, battery lasting about 5-7 days.
