Specifications
Brand Name :
DEHRAY
Model Number :
RDE6500T
Certification :
CE, EURO V, EPA, ISO9001
Place of Origin :
CHINA
MOQ :
N/M
Price :
Based On Order
Payment Terms :
T/T, L/C, D/P, Western Union, D/A
Supply Ability :
500 Sets Per Week
Delivery Time :
20 Working Days
Packaging Details :
Seaworthy Delivery Package/ Wooden Package/ Carton/ Pallet
Product Name :
5KW Diesel Generator
Model No. :
RDE6500T
Power Rate :
5KW
Rated Frequency :
50/60 Hz
Rated Rotation Speed :
3000/3600 rpm
Engine Type :
Single Cyliner
Structure Type :
Air Cooled
Bore Stroke :
86x72
Displacement :
0.418L
Starting System :
12V Electric Starter
Noise Level :
72 dB(A)/7m
Overall Dimensions :
910x530x740 mm
Net Weight :
145 kg
Description

Rated Frequency 50/60 Hz Portable Silent Generators General Generator

Generator set
Rated frequency Hz 50 60
Rated power kVA 4.5 5.0
Max. power kVA 5.0 5.5
Rated voltage V 115/230 120/240
Rated current A 39.1/19.6 41.7/20.8
Rated rotation speed r/min 3000 3600
Generator
Pole No. 2
Phase number Single phase
Excitation mode Self-exciation and constant voltage(with AVR)
Power factor COS 1.0
Insulation grade mm F
Engine
Engine type RD186FAGET
Structure type Single-cylinder, vertical, 4-stroke,
air-cooled, direct-injected
Bore x stroke mm 86×72
Displacement L 0.418
Compression ratio mm 19 : 1
Rated power kW 5.7 6.3
Lubrication system Pressure splashed
Lube oil brand Above CD or SAE 10W-30, 15W-40
Lube capacity L 1.65
Starting system 12V Electric starter
Charging generator capacity V-Ah 12V 36Ah
Fuel consumption ratio g/kW.h 275.1 281.5
Fuel type Diesel : 0# (summer), -10# (winter), -35# (chillness)
Genset
Panel type General panel
Output Receptacle 2-Single phase
Output Connection pole without
Nosie level(7m) dB(A) 72
Fue tank capacity L 15
Overall dimensions mm 910×530×740
Net weight kg 145
