Specifications
Brand Name :
Future Tech
Model Number :
FT3500
Certification :
CE,ISO,ROHS,REC
Place of Origin :
Shenzhen China
MOQ :
Negotiable
Payment Terms :
T/T, Western Union
Model :
FT3500
Capacity: :
3KVA/5 KVA / KW
OUTPUT: :
220/230VAC ±5%
Dimensions:D X W X H(mm): :
482x290x113
Color :
Orange,Green
Warranty :
1 Year Warranty
Description

Home Use 5.5KW Off Grid Hybrid Inverter 220/230V Solar Inverter Max Parallel To 12 Units

This is a multi-functional inverter/charger,combining functionsof inverter,solar charger and battery charger to offer uninterruptiblepower support in portable size. Its comprehensive LCD displayoffers user-configurable and easy-accessible button operationsuch as battery charging current, AC/solar charger priority,andacceptable input voltage based on different applications.

A solar hybrid inverter is a device that combines the functions of a traditional inverter and a solar charge controller, allowing for the integration of solar power into an existing electrical grid or a standalone off-grid system. The key feature of a solar hybrid inverter is its ability to manage both solar-generated electricity and electricity from other sources, such as the grid or a backup generator. This integration enables more efficient use of solar energy and ensures a continuous power supply.

Features:

1. Supporting 24V Lithium Battery

2. Pure sine wave solar inverter

3. Output power factor 1

4. High PV input voltage range

5. Battery equalization function to optimize battery performance and

6. extend lifecycle Inverter running without battery

7. Built-in MPPT solar controller

8. WiFi/GPRS remote monitoring RS485 communication for BMS(Optional)

9. Detachable LCD(Optional)

Application Area:

Office and public facilities, household system, networktransmission equipment, manufacturing, control system,solar energy system, oil field, drilling field operation, etc. Provide stable, reliable and safe solutions for families, islands.ships and other small photovoltaic power systems

MODEL FT3500
CAPACITY 5.5KVA/5.5KW
Parallel Capability Yes,Max to 12 Units
INPUT
Nominal Voltage 220VAC
Acceptable Voltage Range 170-280VAC(For personal Computer)；90-280VAC(For Home Appliances)
Frequency 50/60 Hz (Auto sensing)
OUTPUT
Nominal Voltage 220/230VAC±5%
Surge Power 11000VA
Frequency 50/60 Hz
Waveform Pure Sine wave
Transfer Time 10ms(For personal Computer)；20ms(For Home Appliances)
Peak Efficiency (PV to INV) 96%
Peak Efficiency (Battery to INV) 93%
Overload Protection 5s@>=15C% load; 10s@110%~150% load
Crest Factor 3:1
Admissible Power Factor 0.6-1 (inductive or capacitive)
BATTERY
Battery Voltage 48VDC
Floating Charge Voltage 54VDC
OverCharge Protection 63VDC
Charging Method CC/CV
Solar Charger& AC Charger
Solar Charger Type MPPT
Max.PV Array Power 5500W
Max. PV Array Open Circuit Voltage 500VDC
PV Array MPPT Voltage Range 120VDC-450VDC
Max. Solar Input Current 18A
Max. Solar Charge Current 100A
Max. AC Charge Current 60A
Max. Charge Current 100A
PHYSICAL
Dimensions, D x W x H(mm) 482x290x113
Package Dimension^ D x W x H(mm) 565x380x190
Net Weight (Kgs) 10
Communication Interface USB/RS23 Dry~contact
ENVIRONMENT
Operating Temperature Range -10°C to 50°C
Storage temperature -150 60°C
Humidity 5% to 95% Relative Humidity (Non-condensing)
