Fast And Accurate Concrete Placement Equipment 15Kw Power Output
Fast And Accurate Concrete Placement Equipment 15Kw Power Output
Fast And Accurate Concrete Placement Equipment 15Kw Power Output
Fast And Accurate Concrete Placement Equipment 15Kw Power Output
Specifications
Brand Name :
KEDA / POTENCY
Model Number :
HG34
Certification :
ISO9001:2015
Place of Origin :
CHINA
MOQ :
1 Unit
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
120 Units Per Year
Delivery Time :
45 Working Days
Packaging Details :
1 Unit in 2*40'HQ
Product Category :
Concrete Placing Boom
Boom Sections :
4
Power Output :
15Kw
Placing Radius :
34m
Hydraulic System Pressure :
28MPa
Column Length :
10m
Stationary Height :
22.9m
Working Temperature :
-20℃～48℃
Description

Concrete Placing Boom HG34 The Ultimate Solution for Fast and Accurate Concrete Placement

Applications

■ Widely for horizontal concrete placing at roof of highrise buildings, by using which the overall working

efficiency of the project can be promoted.

■ Support internal climbing through floors and shafts on site with limited space.

Features

1, Modular design, mechanical and electrical integration control, folding boom, tube column, floor frame and shaft frame. Integration of advanced features and product diversification, to achieve a higher product portfolio, improve the applicability of the product.

2, Imported hydraulic and electrical components, adopt quality fast coupling for hydraulic pipelines, which is converted quickly, it can effectively solve the problem of oil leakage in the process of assemblying and dismantling, and avoid the pollution of the environment. Safety and reliability

3, 4 sections R type hydraulic boom, large circular arc, novel and beautiful appearance, compact structure, and the lightweight design of the boom, which reduced the weight of the whole machine..

4, Easy to transport and install.

5, Stepless speed control, more stably to operate.

Specifications

Model HG34
Boom Section 4
Delivery pipe dimension (outside diameter × thickness) (mm × mm) Φ133×4
Delivery hose dimension (inside diameter × length) (″×mm) 5″×3000
Radius of placing boom (m) 34
Stationary height (to the joint between the end of the boom and Swivel table) (m) 22.9
Hydraulic foldable arm sections 1st section 9.6m
2nd section 8.2m
3rd section 8.0m
4th section 7.9m
Boom articulation (°) 1st section －4.2～82.5
2nd section 0°～180°
3rd section 0°～180°
4th section 0°～180°
Slewing range (°) 360
Power of motor (kW) 15
Pressure of hydraulic system (MPa) 28
Type of hydraulic oil ESSO NUTO H46 or H32
Interval of climbing frame (m) Climbing 3.0～4.2
Placing concrete 6.0～8.4
Resting
Mode of operation 1. cable remote control
2. radio remote control
Power 380V/50Hz
Wind speed Placing concrete ≤60 km/h
Climbing ≤28 km/h
Working temperature -20℃～48℃
