Product Description:

The KD12A-1BCD(L) is a powerful drill machine that can handle any type of terrain within a slope of 14°. Featuring a high-power diesel engine, this drill machine can transition at a speed of 5Km/h, achieving high-speed movement for optimal productivity.

The drilling arm structure of this machine uses a polar coordinate mechanical translation with independent intellectual property rights. This allows for rapid positioning between each borehole, ensuring that no area on the entire working face is left untouched. This means that there are no blind spots or dead corners when using the KD12A-1BCD(L), making it an efficient and effective tool for drilling operations.

If you are working in small mines, the KD12A-1BCD(L) is the perfect machine for alleyway operations. Its compact design allows for easy maneuvering, while its powerful capabilities ensure that you can get the job done quickly and efficiently.

Features:

The entire machine features an advanced full hydraulic drive system that can achieve rock drilling speeds as fast as 0.8-2 meters per minute. With user-friendly functions like automatic stop of impact at the endpoint, automatic anti-jamming drill, and induction of water slag discharge, this system is both easy to operate and safe and reliable.

Thanks to its compact structure and low center of gravity, this machine boasts a small body with a strong climbing ability, flexible maneuverability, and stable operation. It utilizes track walking to enable rock drilling on a 14° inclined slope. The hydraulic rock drilling mechanism is highly flexible and capable of performing rock drilling operations on the working face, roof, side walls, and floor of the tunnel. Moreover, this machine can be utilized to drill anchor holes of varying sizes according to the specific needs of the section.

Applications:

The machine is primarily designed for conducting the excavation and digging tasks in small to medium-sized tunnels, culverts, and tunnels in various fields including mining, metallurgy, hydropower, railway, and highway constructions.

The equipment facilitates electric and diesel engine walking which provides an added advantage of enhanced transfer speed, construction efficiency, and construction quality. When compared to electric engine walking, diesel engine walking significantly increases the effectiveness of the machine, making it a reliable choice for those in need of superior equipment performance.

Packing and Shipping:

Product Packaging:

• 1 Jumbo Rock Drill machine
• 1 set of drill bits
• 1 user manual

Shipping Information:

• Shipping weight: 2000kg
• Shipping dimensions: 200cm x 150cm x 180cm
• Shipping method: Freight
• Shipping time: 5-7 business days

FAQ:

Q: What is the brand name of this rock drill?

A: The brand name of this rock drill is POTENTIAL / POTENCY.

Q: What is the model number of this rock drill?

A: The model number of this rock drill is KD12A-1BCD(L).

Q: Where is this rock drill manufactured?

A: This rock drill is manufactured in CHINA.

Q: Is this rock drill certified?

A: Yes, this rock drill is certified with ISO9001:2015.

Q: What is the minimum order quantity for this rock drill?

A: The minimum order quantity for this rock drill is 1 unit.

Q: Is the price negotiable?

A: Yes, the price is negotiable.

Q: What is the packaging detail for this rock drill?

A: The packaging detail for this rock drill is 1 unit in 1*40'HQ.

Q: What is the delivery time for this rock drill?

A: The delivery time for this rock drill is 45 working days.

Q: What are the payment terms for this rock drill?

A: The payment terms for this rock drill are T/T or L/C.

Q: What is the supply ability for this rock drill?

A: The supply ability for this rock drill is 120 units per year.
