Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width
Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width
Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width
Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width
Specifications
Brand Name :
EM
Place of Origin :
CHINA
MOQ :
1 set
Price :
FOB SHANGHAI USD
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 SETS
Delivery Time :
25 WORKING DAYS
Packaging Details :
WOODEN CASE
Warranty :
1 year
Material :
AL film,Plastic,Paper,PE film
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support,Field installation
Voltage :
380V
Power(w) :
3.2kw
Speed :
30-60bags/min
Bag width :
50-160mm
Application :
tea bag filling and packing
Description

Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width

EMT1100 Automatic DOUBLE tea bag filling and packing machine

1. The inner bag packing machine and outer bag packing machine can be used separately, which is flexible and practical

2. The outer bag is packaged with heat-sealed composite material, and the pattern can be customized according to customer requirements, so as to automatically cut off the calibration position

3. Nitrogen charging device can be added to extend the retention period and freshness of the product

4. Configurable production date random printing device, making production more standardized and consumption safer Scope Applicable scope Black tea, green tea, herbal tea, health care tea, formula tea, eight treasure tea, Chinese medicine pieces and other products of automatic bag bubble packaging.

project
Measuringrange 1-10g

Metering accuracy

 ±0.15g

Measurement method

 4 heads tea weighter

Packaging speed

 30-40bags/min

Packing method

Inner bag:3 sides sealing

Outer bag:hot sealing
Packing size

Inner bag:120mm (48*50 mm) outer bag:≥80*90 mm

Inner bag:140mm (58*60 mm) outer bag:≥ 80*100 mm

Inner bag:160mm ( 68*70 mm) outer bag:≥ 90*110 mm
Packaging

Inner bag: ultrasonic sealing materials such as nylon mesh cloth, non-woven cloth, PLA corn fiber, etc

Outer bag: heat-sealable composite material

Material specification

 Inner bag:120 mm ,140 mm ,160 mm outer:≥ 160 mm

Unwinding quantity

 2rolls

Unwinding diameter

 ≤Φ 400 mm

Inside of paper roll

 Φ 76 mm

Number of operators

 1 worker
Air pressure ≥ 1.2 Mpa
power 3.2 Kw
size

Inner bag machine:L 1600 * W 800 * H 1900 mm

Outer bag machine:L 1100 * W 950 * H 1620 mm
weight 950 Kg

Coffee Filling And Packing Machine 3.2kw Power 50-160mm Bag Width
