Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate
Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate
Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate
Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate
Specifications
Place of Origin :
Jiangsu, China
Certification :
SGS,ISO,CE,ASME,DNV
Supply Ability :
20 Set/Sets per Month
Packaging Details :
Good Packed by plastic wrapo in Iron or wooden pallet, Suitable for land transporation and sea shipping.
MOQ :
>=1 Sets
Price :
Negotiable
Model Number :
60-10000L
Payment Terms :
L/C, T/T
Type :
Reaction Kettle
Warranty :
1 year
After-sales Service Provided :
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Port :
Shanghai
Selling point1 :
Long Service Life
Selling point2 :
Good Welding Process
Description

Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate

Product description

Reaction Kettle is used in the process of hydrolysis, neutralization, crystallization,distillation and evaporation in pharmaceutical, chemical, food, light and other industries. It can use SS304, SS316L, Titanium, Hastelloy, PTFE lined and other materials to manufacture. Several mixing types are available, such as anchor, frame and oar, etc. Cycloidal pinwheel reducer, variable-speed reducer and others could be applied in the rotating mechanism.

Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate

Product composition

The whole reaction equipment can be equipped with condenser, condensate receiver, circulation pump, pipes, etc, accodring to customer's requirement and technology product processing.
Stainless Steel Polished Reaction Kettle Gas Tank With ASME Certificate

Technical parameter

Model 300L 400L 500L 600L 1000L 2000L 3000L 5000L
Vessel Op. Temp. (MPa) 0.1-10Mpa
Jacket Op. Temp. (MPa) 0.1-10Mpa
Motor Power (Kw) 0.55 0.55 0.75 0.75 1.1 1.5 1.5 2.5
Stirring Speed (r/m) 36~53
Diameter (mm) 900 1000 1150 1150 1400 1500 1700 2000
Height (mm) 1800 1900 2200 2300 2600 2900 3200 3700
Heat Exchanging Area (m2) 2 2.4 2.7 3.1 4.5 7.5 8.6 10.4
