NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
Specifications
Brand Name :
Rattm Motor
Model Number :
NMRV040
Certification :
CE CCC
Place of Origin :
China
MOQ :
1piece
Price :
28.9--32.3
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
5000
Delivery Time :
2-7 work days
Packaging Details :
Independent anti-collision foam+outer box packaging for each product
Model :
NMRV040
Speed Ratio :
5:1-80:1
Input Bore Size :
9mm,11mm, 14mm
Output Bore Size :
18mm
Color :
Blue/Silver
Description

Round Flange NMRV040 Worm Reducer Gear Gearbox 71B5 71B14 63B5 63B14 56B5 And 9mm 11mm 14mm Input Output 18mm

NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input

Feature:


Model:NMRV040

Type:Worm-Gear Reducer

Speed Ratio:10:1 15:1 20:1 25:1 30:1 40:1 etc.

Input Bore Size:9mm,11mm, 14mm

Output Bore Size:18mm

Goods Color:Blue / Silver

Advantages:

High-quality aluminum alloy enclosure, thermal performance, large carrying capacity.

The multi-faceted installation.

Smooth transmission, low noise.

NMRV 040 Parameters (Aluminum shell weight 2.4KG)

Center

Distacne A

 Motor Flange The hole diameter of shaft (DM)

PAM

IEC

 N M P bm tm I Transmission Ratio
7.5 10 15 20 25 30 40 50 60 80 100
NMRV040 71B5 110 130 160 5 16.3 14 14 14 14 14 14 14 - - - -
71B14 70 85 105
63B5 95 115 140 4 12.8 11 11 11 11 11 11 11 11 11 11 11
63B14 60 75 90
56B5 80 100 120 3 10.4 - - - - - - - 9 9 9 9

NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input

NMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm InputNMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm InputNMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm InputNMRV040 Gear Worm Reducer 71B5 71B14 63B5 63B14 56B5 9mm 11mm 14mm Input
