Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
Specifications
Brand Name :
Shengli
Model Number :
WZL
Certification :
CE and ISO
Place of Origin :
China
MOQ :
1 SET
Price :
Negotiable
Supply Ability :
200-300 SET PER MONTH
Delivery Time :
1 MONTH
Packaging Details :
NAKED OR WOODEN CASE
Capacity :
0.5cbm-20cbm
Material :
mild steel, sus304, sus316L, sus321
Auxiliary :
spraying, heating and cooling
Inlets :
feeding ports, cleaning port, vent
Power :
11kw-132kw
Speed :
10rpm-60rpm
Description

twin shafts blender, twin shaft mixer, double shaft mixer, double paddle mixer, two shaft paddle mixer

General introduction:

Double shaft mixer is widely applied in chemical, biological, and construction material.

It can mix powder, granule, and fiber especially in battery, construction, environmental, mineral and agricultural line. cement mixer, fiber cement mixer etc.


Product features:

With the most powerful motor, material can be mixed evenly in the shortest time.

It is particularly good at mixing material with big difference in gravity, mesh size, fluidity

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer

Data table

specification WZL-0.3 WZL-0.5 WZL-1 WZL-2 WZL-3 WZL-4 WZL-6 WZL-10 WZL-15 WZL-20
working capacity(m³) 0.18 0.3 0.6 1.2 1.8 2.4 3.6 6 9 12
working capacity(kg) 200 300 600 1200 1800 2500 3600 6000 9000 12000
speed(RPM) 60 60 53 43 43 35 35 29 22 18
power(KW) 5.5 7.5 11 22 30 37 44 60 90 150
weight 650 900 1300 2300 2800 3400 5000 6000 8500 12000
length 1600 1800 2400 2800 3200 3400 3700 4000 4600 5200
width 850 1000 1400 1700 1950 2000 2200 2600 3100 3500
height 950 1100 1800 1950 2000 2000 2300 2600 2800 3000

WORKING PRINCIPLE:

Double shaft paddle mixer is a batch mixer with two counter-rotating shaft that are equipped with ten paddles
they overlap each other following the driven unit, Blades generate centrifugal force during high speed rotation, spilling the material to the upper part in the barrel then material falling down( the vertex of material is in a so called instant non-gravity state). Driven by the blades material is mixed back and forth: also sheared and separated by the meshing space between the twin shafts ast and evenly mixed in the end

When mixing:

1. The horizontal axes make the material move up and down.

2. Rotation at opposition direction of the double axes makes materials exchange from left to right.

3. Paddle stirrers push material at angle 45 to move circularly in the cylinder, and the materials can reach good mixing effect under the movement of radial and axial orientation

1. Flexible material selection

Material can be carbon steel, manganese steel, ss304, 316L and 321;

besides, different material can also be used in combination between the part contact with the raw material and the parts don’t contact with the raw material.
Surface treatment for stainless steel include sandblasting, wiredrawing, polishing, mirror polishing, all can be used in different parts of a mixer

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer

2. Reliable driven unit

The driven unit, power and speed are varied according to different raw material, starting method, and processing.

Because of the meshing relationship for the paddles, the double shaft driven unit is required to be equipped with synchronous ability.

The four different driven combination launched by Shengli Co. can meet different requirements of two synchronous gear box, double output gear box

double synchronous planetary gear box, and the combination of reducer and chain.

The combination of Sk-series double synchronous gear box is the best configuration for double shaft paddle mixer.

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer

3. High efficiency mixing unit

According to the properties of raw materials, the paddle can be adjusted and designed accordingly

for example adding wear-proof plate, Teflon plate, and saw-toothed paddle.
Double shaft paddle mixer can be also added high speed breaking bar inside the barrel, scattering material following its flow.

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer

4. Excellent discharging unit
Standard valve for double shaft paddle mixer is twin pneumatic planar flap valves.

When close the valve, the planar flaps match the mixing barrel perfectly, this makes no mixing dead zone and better mixing effect

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer

Simple production mixing line as mortar blender, cement blender, putty mixer, paint powder blender, etc.

Stable Running Twin Shaft Paddle Mixer , Convenient Installation Double Shaft Mixer
