Low Energy Consumption Pulse Bag Filter Environmental Protection Machinery Low Noise
Low Energy Consumption Pulse Bag Filter Environmental Protection Machinery Low Noise
Low Energy Consumption Pulse Bag Filter Environmental Protection Machinery Low Noise
Low Energy Consumption Pulse Bag Filter Environmental Protection Machinery Low Noise
Specifications
Brand Name :
HAOFENG
Place of Origin :
CHINA
MOQ :
1 set
Price :
1000-100000 USD /RMB
Payment Terms :
T/T
Supply Ability :
20 sets/month
Delivery Time :
5-30 work days
Packaging Details :
upon request
advantage :
Less investment, simple operation,
model :
multiple models are available
feature :
low noise,energy-saving
Description

Bag filter is a dry dust removal equipment that uses a new type of bag filter medium to capture dust in dusty gases. The dust removal performance of bag filter is not affected by the dust concentration and gas volume of the dust source. The dust particle size of the captured object exceeds 0.2 microns, and the capture efficiency can generally reach over 99%. For particles with a size of 1 micron, the capture efficiency is almost 100%. The outlet dust concentration can reach or exceed national standards, generally reaching 5-30mg/m³.

Characteristics of dust collector

1. The appearance design of the dust removal equipment is arbitrary and does not affect the dust removal effect. Small size, high wind speed, low noise, low energy consumption, and low maintenance costs in the later stage.

2. The dust removal equipment adopts pulse cleaning and can also be repaired, maintained or replaced with bags during normal operation.

3. Adopt a segmented pulse dust cleaning method, with multiple dust collection chambers taking turns cleaning dust.

Technical performance

Specification and model

filter area

m2

dust concentration

g/m3

filtration velocity

m/min

 Filter air volum3/h

resistance

H omm

efficiency

%

External dimensions

mm

 weight
Specification and model

Filter area

m2

 dust concentration g/m3 Filter air speed m/min Air volumem3/h resistance efficiency

overall dimension

LxWxH

 weight
MC24-II 18 ＜15 2-4 2160-4320 120-150 99.5 1090*1678*3667 1133
MC36-II 27 ＜15 2-4 3240-2480 120-150 99.5 1490*1678*3667 1485
MC48-II 36 ＜15 2-4 4320-8640 120-150 99.5 1890*1678*3667 1495
MC60-II 45 ＜15 2-4 5400-10800 120-150 99.5 2290*1678*3667 1730
MC72-II 54 ＜15 2-4 6480-12960 120-150 99.5 2690*1678*3667 1950
MC84-II 63 ＜15 2-4 7650-15120 120-150 99.5 3090*1678*3667 2230
MC96-II 72 ＜15 2-4 8640-17280 120-150 99.5 3650*1678*3667 2400
MC120-II 99 ＜15 2-4 10800-21600 120-150 99.5 4450*1678*3667 2870
