Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
xinda
Model Number :
GK-200
Supply Ability :
1 Set/Sets per Month
Packaging Details :
plywood case
MOQ :
1 Set/Sets
Price :
Negotiable
Type :
Granulator
Application :
Granules
After-sales Service Provided :
Engineers available to service machinery overseas
Port :
shanghai
Description

Quality Dry Granulator Briquette Making Machine Adjustable Roll Feeding Speed

Main application:

The finished granules from this machine can be made into troches or capsules, etc. The granulator is mainly used by the trades of pharmaceutical, chemical, foodstuff, etc, especially suitable for the granulating of those materials that cannot be done by the wet granulating method.

pharmacy: troches, capsules

Foodstuff: foodstuff granules, seasoning granules

Plastic: all kinds of shaped plastic granules

Chemical: granules of activator, pigments and washing agent

Characteristics

1 Even density of dry granules, good disaggregation and high granule ratio

2 Unique feeding structure guarantees efficient material feeding

3 Circulated cooling water refuses sticky problems

4 No need ofwettngagent or second-time drying, less procedures, high efficiency and low cost

5 Advanced electric hydraulic pressure, easy to operate with high automation

6 No pollution due to closed operation, so as to meet the sanitation standard7 Especially suitable for the granulating of those material which cannot be done by wet granulating method

MODE

80 MODEL 80

120 MODEL 120

200 MODEL 200

(kg/h) Capacity

20-60

30-100

50-200

(L) Hopper volume

3

5

8

(mm)Roll size

200×80

200×120

250×200

(T) Max roll pressure

10×2

15×2

25×2

(r/min )Roll speed

2-20(adjustable)

2-20(adjustable)

2-30(adjustable)

(rpm) feeding speed

6-60(adjustable)

6-60(adjustable)

6-60(adjustable)

(kw)roll drive power

4

7.5

11

(kw) feeding drive power

1.5

2.2

3

(kw)granulating drive power

1.1

2.2

2.2

(kw)oil pump drive power

0.75

1.1

2.2

(MPa)max hydraulic pressure

20

30

50

roll & feeding speed control

Electromagnetic speed control or frequency changing speed control

Electromagnetic speed control or frequency changing speed control

Electromagnetic speed control or frequency
changing speed control

(kg) Weight

2300

2800

3500

(mm)Overall size (L×W×H)

1540×1250
×2400

1800×1650
×2600

2200×2500
×2200
