SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
XD
Model Number :
150
Certification :
GMP ISO
Supply Ability :
200 Piece/Pieces per Quarter
Packaging Details :
to be wrapped by a plastic film, then packed in a wooden case according to size of machine, ususally under export standard
MOQ :
1 Piece/Pieces
Price :
Negotiable
Machine Type :
Granulator
Condition :
New
Product Type :
pharmacy
Voltage :
380V
Dimension(L*W*H) :
810*445*1345(mm)
Specification :
SUS 304
After-sales Service Provided :
Engineers available to service machinery overseas
Power(W) :
1.1
Port :
Shanghai
Description

SUS 304 Powder Granulator Machine FZ Series Grinding Stirring 810*445*1345 Mm

1. Main application

(1) Pharmacy: Raw material grinding, wet process of granules, dry material granulation

(2) For those tablets not in requirement, they can be recycled according to the size of particles.

(3) Foodstuff: For the reuse of biscuits

(4) Others: For the grinding and granulation of coarse materials, block materials and agglomerated materials

2. Working method

(1) Raw materials entering the feeding gate will be will fall into coneshaped working chamber and are sheared by rotary knives and mesh surface.

(2) The material is cut into small particles and released from the sieve.

(3) The granule size is decided by the distance of mesh size, rotary knives and sieve as well as the rotary knife speed.

3. Technical Data

MODEL MODEL 150 MODEL 300 MODEL 450 MODEL 700 MODEL 1000
Capacity(kg/h) 15-150 30-300 45-450 70-700 100-1000
Size 6-80 6-80 6-80 6-80 6-80
transfer base temperature increase < 30 < 30 < 30 < 30 < 30
speed control range(rpm) Single speed 2800; frequency conversion speed control 300-3600
motor power(kw) 1.1 1.5 2.2 3 5.5
height of discharge gate from floor(mm) 650 650 659 690 720
Overall size (L×W×H) (mm) 810×445 ×1345 810×445 ×1345 920×445 ×1430 1000×500 ×1530 1100×560 ×1785
