Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz
Specifications
Model Number :
FL
Place of Origin :
Jiangsu, China
Brand Name :
xinda
Certification :
CE ISO SGS
Supply Ability :
10 Piece/Pieces per Month
Packaging Details :
wooden case
MOQ :
1 Piece/Pieces
Price :
Negotiable
Type :
Fluid Bed Drying Equipment
Condition :
New
Voltage :
380V 50Hz
Power(W) :
10Kw
After-sales Service Provided :
Engineers available to service machinery overseas
Warranty :
1 year
Port :
shanghai
Description

Fluidized Powder Granulator Machine Fluid Bed Drying Equipment 380V 50Hz

Main Application
It is widely applied for the capsules granule, tablets and the herb granule
Characteristics
Integrated the processing of mixing, granulating and drying, this machine has the features of high automation, quick granulation and quick drying.
Mono or multi-kinds of powder materials for granulation are to be fluidized within the fluidized bed and to be mixed, and then the bond agent is to be atomized by the special jet gun and to be sprayed on the fluidized interface. Meantime, the powder material is gradually granulized in dry air and the volatilized water content is discharged by blower fan.
1. control cabinet
2. transfusion vehicle
3. Main frame
4. Air heater
5. Medium efficient filter
6. Muffler
7. Air compressor
8. Draught fan
Model MODEL 5 MODEL15 MODEL30 MODEL60 MODEL120 MODEL200 MODEL300 MODEL500
Capacity Min (kg/group) 4 10 20 40 80 160 250 350
Max (kg/group) 6 20 40 80 160 250 350 550
Raw material vessel volume (L) 22 45 100 220 420 670 1000 1600
Draught fan power Normal (kw) 2.2 4 5.5 11 15 22 30 37
Filter and cyclone separator (kw) 3 5.5 7.5 15 18.5 30 37 45
Steam Consumption (kg/h) 23 42 70 141 211 282 366 450
Pressure (Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6
Thermal heating power(selected by customer)(kw) 7 12 4.5 21 30 47 70 110
Compressed air Consumption (m3/min) 0.3 0.3 0.4 0.6 0.8 0.9 1.5 2
Pressure (Mpa) 0.4-0.6
Working temperature (℃) Room temperature -120℃ auto adjustment
Water content of product (%) Mini0.5
Recycling ratio (%) ≥99
Equipment noise (dB) ≤70
Main frame height (mm) 2100 2200 2300 3000 3300 3800 4100

Working Method
