Specifications
Place of Origin :
Jiangsu, China, Jiangsu, China (Mainland)
Brand Name :
Xinda
Model Number :
FZ-300
Certification :
ISO CE
Supply Ability :
10 Piece/Pieces per Month
Packaging Details :
wooden box
MOQ :
1 Piece/Pieces
Price :
Negotiable
Type :
Granulator
Application :
Powder
Voltage :
380v
After-sales Service Provided :
Engineers available to service machinery overseas, Engineers available to service machinery overseas
Warranty :
1 year
Port :
Shanghai
Capacity :
30-300
Size(Mesh) :
6-80
Description

Xinda 2020 FZ Series Frequency Stepless Governor Grinding & Stirring Granulator

FZ Series Frequency Stepless Governor Grinding & Stirring Grinder Granulator

Main application
Pharmacy: raw material grinding, wet process of granules, dry material granulation, For those tablets not in requirement,they can be recycled according to the size of particles.
Foodstuff: for the reuse of biscuits
Others: for the grinding and granulation of coarse materials, block materials and agglomerated materials
Working method
Raw materials entering the feeding gate will be will fall into cone-shaped working chamber and are sheared by rotary knives and mesh surface. The material is cut into small particles and released from the sieve. The granule size is decided by the distance of mesh size, rotary knives and sieve as well as the rotary knife speed.

Model Model 150 Model 300 Model 450 Model 700 Model 1000
Capacity(kg/h) 15-150 30-300 45-450 70-700 100-1000
Size(mesh) 6-80 6-80 6-80 6-80 6-80
Transfer base temperature increase(℃) < 30 < 30 < 30 < 30 < 30
Speed control range(rpm) Single speed 2800; frequency conversion speed control 300－3600
Motor power(kw) 1.1 1.5 2.2 3 5.5
Height of discharge gate from floor(mm) 650 650 690 690 720
Overall size (L×W×H)(mm) 810×445
×1345		 810×445
×1345		 920×445
×1430		 1000×500
×1530		 1100×560
×1785
