Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
XINDA
Model Number :
ZS-350
Certification :
CE CCC CQC ISO
Supply Ability :
100 Set/Sets per Month
Packaging Details :
WOODEN CASE
MOQ :
1 Set/Sets
Price :
Negotiable
Condition :
New
Type :
Separating Plant
Product Type :
powder
Voltage :
380V 50Hz or as per customer requirement
Power(W) :
0.55kw
Weight :
150
Dimension(L*W*H) :
640*640*1060
Specification :
SUS 304
Experience :
Over than 15 years professional experience
Warranty :
1 year
After-sales Service Provided :
Engineers available to service machinery overseas
Port :
SHANGHAI
Description

Stainless Steel Powder Sifter Machine Granule Vibrating Screener Pharmaceutics Chemcial Foodstuff

ZS Series Vibrating Screener

Main Application
The machine is suitable for flow operation, and is the ideal equipment for sifting out the granules in different sizes and proportion and for continuous material Delivering.

Structure and Characteristics
The machine is composed of the hopper, vibration chamber, clutch, motor, etc. The vibration chamber is equipped with eccentric wheel, rubber soft pieces, main
Shift, bearings, etc. When the adjustable eccentric weight passed its gravity to the central line of main shift by the driving of motor to break the balance, then
Under the centrifugal force, the orbit spire of target material is forced to change its way in the chamber. The size of swing of the weight regulator van be adjusted
According to different kinds of target material or the number of mesh. The whole machine has the specialties of compact structure, small volume, nondust flying, low
Noise and high output, low energy consumption, easy to be moved and maintained.

Technical Data

Model Model350 Model 515 Model650
Capacity(kg/h) 60-500 60-1300 180-2000
Number of mesh 12-200 12-200 12-200
Motor power(kw) 0.55 0.75 1.50
Speed of principal axis (r/min) 1380 1370 1370
Weight (kg) 100 180 250
Overall size (L×W×H)(mm) 540×540 ×1060 710×710 ×1290 880×880 ×1350
