High Quality Xinxiang cocoa powder milk vibrating screen filter sieve
High Quality Xinxiang cocoa powder milk vibrating screen filter sieve
Specifications
Brand Name :
YIHU, YIHU
Model Number :
OEM
Certification :
CE
Place of Origin :
Henan, China
MOQ :
1 - 99 Sets
Price :
$1200~5000 set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Set/Sets per Month
Delivery Time :
7~15 work days
Packaging Details :
Packing machine with wooden box, or delivery with Container without packing, to prevent them from destroying during transportation. Then, we will choose the most convenient and economic way to delivery goods.High Quality Xinxiang cocoa powder milk vibrati
Type :
Circular
Voltage :
380-480V
Warranty :
1 Year
Function :
Screening\separation
Product Name :
High Quality Xinxiang cocoa powder milk vibrating screen filter sieve
Color :
Customized
Description

High Quality Xinxiang cocoa powder milk vibrating screen filter sieve

Product Description

Ultrasonic sieving system consists of ultrasonic generator, energy converter and resonant ring. Ultrasonic generator produces high frequency oscillation and energy converter turns it into high-frequency sinusoidal longitudinal shock wave. This shock wave gets to resonant ring to make it resonate. Then resonant ring puts oscillation transmission to screen surface evenly. Materials on the surface will do low-frequency three dimensional vibration and ultrasonic vibration at the same time. This can prevent mesh clogging and improve yield and quality of screening.

High Quality Xinxiang cocoa powder milk vibrating screen filter sieve

Product Details

Ultrasonic Vibrating Screen is widely used in metallurgy powder, electromagnetic materials, metal powder, iron powder, zinc oxide, alumina powder, alloy powder, molybdenum powder, cobalt powder, carborundum, copper, nickel powder, silica powder, titanium oxide, tungsten carbide, tungsten powder, titanium powder , stainless steel powder etc.

Model Power(KW) Layers Machine Diameter(mm) Dimensions(mm)
CSB-400 0.18 1-5 320 420*420*580
CSB-600 0.55 1-5 550 580*580*680
CSB-800 0.75 1-5 750 800*800*680
CSB-1000 1.5 1-5 950 900*900*780
CSB-1200 1.5 1-5 1150 1160*1160*880
CSB-1500 2.2 1-5 1450 1360*1360*980
CSB-1800 2.2 1-5 1750 1850*1850*1130
Features

1. The feeding port and the discharging port can be arbitrarily changed to facilitate the screening mechanical arrangement.
2. the structure is simple, less blocking holes, automatic cleaning anti-blocking network device
3. small size, light weight, easy to install, easy to move
4. unique grid structure, easy to change the net, easy to operate, easy to clean
5. high vibration efficiency, compact design and durability, any powder and adhesive can be screened
6. fully enclosed structure, no dust pollution, low noise, low energy consumption, in line with environmental requirements.
7. a wide range of screening, dry wet screening can be, the replacement of the screen is simple

Working principle

It uses vertical motor as the source of vibration, equipped eccentric hammer on the both sides of motor ,change cir cum rotate to level ,upright and incline movement,then pass these three movement to surface of the screen. Adjust the phase angle on the both sides of the top and bottom to change the movement track of the surface screen. This will help to screen different materiel in different situation successfully.
Packaging & Shipping

Packing machine with wooden box, or delivery with Container without packing, to prevent them from destroying during transportation.

Then, we will choose the most convenient and economic way to delivery goods.

Besides, if our customer have specific demand with delivery, we can make it.
