Specifications
Brand Name :
Xinguang lithium battery
Model Number :
12V 65Ah
Certification :
CE,ROHS,UN38.3,MSDS
Place of Origin :
China
MOQ :
5 groups
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
60,000kWh
Delivery Time :
15-20 days for samples, 20-30 days for bulk order
Packaging Details :
Standard export carton, wooden case, pallet etc.
Type :
li-ion 18650 battery
Size :
customized
Cycle life :
>2000times
Application :
solar system
Nominal voltage :
12V
Warranty :
1 Year/12months
Product name :
12V 65Ah Polymer Lithium Battery Long Life Lithium Solar Batteries
Oem/odm :
Yes(Accepted)
Description

12V 65Ah Polymer Lithium Battery Long Life Lithium Solar Batteries

12V 65Ah Li - Ion 18650 Long Life Solar Polymer Lithium Battery

Specifications

Nominal Voltage 12.8V
Nominal Capacity 65Ah
Energy 769Wh
Cycle Life >2000 cycles @ 1C 100% DOD
Internal Resistance(AC) ≤30mΩ
Efficiency of Discharge 96~99% @1C
Charge Voltage 14.6±0.2V
Charge Current 30A
Max Charge Current 60A
Charge Cut-off Voltage 15.6±0.2V
Continuous Current 80A
Max.Pulse Current 100A(<3s)
Discharge Cut-off Voltage 8V
Charge Temperature 0℃ to 55℃ (32F to 131F)
Discharge Temperature .-20℃ to 60℃ (-4F to 140F)
IP Class IP65
Plastic Case ABS
Approx.Dimensions 260mm*168mm*214mm (10.24in.*6.61in.*8.43in.)
Approx.Weight 8.50kg (18.74lbs)

Key Features

  • Longer Cycle Life : Offers up to 20 times longer cycle life than lead acid battery.
  • Light Weight : About 40% of the weight of a comparable lead acid battery .
  • Higher Power : Delivers twice power of lead acid battery, high discharge rate
  • Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
  • Wide Temperature Range : -20℃~60℃

Quality Control

Quality Control

We do below test before delivering

Capacity test

High current discharge test

Low temperature test

Short circuit test

Over charging test

Over discharging test

Cycle performance test

Crush test

Impact test

Vibration test

High temperature test

Applications

Solar/wind energy storage
Wheelchairs and scooters

Back-up power for small UPS

Golf trolleys
Electric bikes

Electric scooter

12V 65Ah Li - Ion 18650 Long Life Solar Polymer Lithium Battery

Advantages of battery:

Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
Higher Power: Delivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity.
Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Increased Flexibility: Modular design enables deployment of up to four batteries in series and up to ten batteries in parallel.
Wider Temperature Range: -20℃~60℃.

Packing and shipping

• Fedex/DHL/UPS/TNT for sample . Door to Door

• By Air or by Sea for Bulk goods , for FCL . Airport Port receiving

• Customers specifying freight forwarders or negotiable shipping methods

• Delivery Time: 7-15 days for samples , 25-35 days for bulk goods time

12V 65Ah Li - Ion 18650 Long Life Solar Polymer Lithium Battery

24 hours customer service, waiting for your inquiry!

12V 65Ah Li - Ion 18650 Long Life Solar Polymer Lithium Battery

Quick delivery

Fast delivery is key factor for clients to compete in the market. We attach much importance to quick delivery as much

as we do in our LiFepo4 lithium battery quality. We will keep our clients updated with tracking number all the time and latest tracking info until the order of LiFePO4 lithium Battery arrives at our clients safely.

Quick delivery

Fast delivery is key factor for clients to compete in the market. We attach much importance to quick delivery as much

as we do in our LiFepo4 lithium battery quality. We will keep our clients updated with tracking number all the time and latest tracking info until the order of LiFePO4 lithium Battery arrives at our clients safely.

Packing and shipping

• Fedex/DHL/UPS/TNT for sample . Door to Door

• By Air or by Sea for Bulk goods , for FCL . Airport Port receiving

• Customers specifying freight forwarders or negotiable shipping methods

• Delivery Time: 7-15 days for samples , 25-35 days for bulk goods time

Packing and shipping

• Fedex/DHL/UPS/TNT for sample . Door to Door

• By Air or by Sea for Bulk goods , for FCL . Airport Port receiving

• Customers specifying freight forwarders or negotiable shipping methods

• Delivery Time: 7-15 days for samples , 25-35 days for bulk goods time

Packing and shipping

• Fedex/DHL/UPS/TNT for sample . Door to Door

• By Air or by Sea for Bulk goods , for FCL . Airport Port receiving

• Customers specifying freight forwarders or negotiable shipping methods

• Delivery Time: 7-15 days for samples , 25-35 days for bulk goods time

Advantages of battery:

Advantages of battery:Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
Higher Power: Delivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity.
Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Increased Flexibility: Modular design enables deployment of up to four batteries in series and up to ten batteries in parallel.
Wider Temperature Range: -20℃~60℃.
