1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
Specifications
Place of Origin :
Fujian, China (Mainland)
Brand Name :
XGMA
Model Number :
XGMA50
Certification :
CE/ISO9001
Price :
Negotiable
MOQ :
1 Piece/Pieces
Condition :
New
Type :
Powered Pallet Truck
Power Souce :
Diesel Engine
Rated Loading Capacity :
5000kg
Max. Lifting Height :
3000mm
Min. Lifting Height :
85mm
Fork Length :
1070mm
Fork Width :
150mm
Overall Dimensions :
2680x1225x2120mm
After-sales Service Provided :
No overseas service provided
Name :
5 ton Diesel Forklift
Color :
Red
Loading Capacity :
2000-5000kg
Power type :
Diesel Forklift
Engine :
NISSAN
Load Center :
500 Mm
Model :
FD-Forklift Diesel
Mast :
2 Stage/3 Stage
Tire :
Pneumatic Standard
Description

Mitsubishi S4S Engine part 5 ton forklift

Specification

Product Model Unit CPCD80-2 CPCD80-2J
Rated Lifting Capacity kg 8000 8000
Deadweight kg 10800 10800
Fork: L x W x H mm 1600x180x80 1600x180x80
Minimum Turning Radius mm 4200 4200
Overall Dimensions (LxBxH) mm 5757x2066x2715 5757x2066x2715
Maximum Travel Speed km/h 26 26
Gradeability % 20 20
Load Center Distance mm 600 600
Tilt Angle of Mast(F/B) ° 6° /12° 6° /12°
Distance from the center line of the Front axle to the fork surface mm 747 747
Lifting Height mm 3000 3000
Free Lifting Height mm 160 160
Minimum Ground Clearance mm 180 180
Track (Front/rear) mm 1494/1600 1494/1600
Wheelbase mm 2700 2700
1600x180x80mm 5 Ton Forklift Mitsubishi S4S Engine 3000mm Lifting Height
Tyre
Front
4X8.25-20-14PR
4X8.25-20-14PR
Rear
2X9.00-16-14PR
2X9.00-16-14PR
Engine
Model
LR6108G6B
6BG1
Rated Power/ Speed
kw/r • p • m
81/2300
84.6/2200
Max. Torque/ Speed
N • m/r • p • m
393/1600-1800
410.9/1400-1600
Fuel Consumption Rate
G/kw.h
242
230
FAQ

1. What's the Certificate do you have?
XGMA workshop meet with the ISO9001 Quality System. And all of our products are with CE certificate.


2. Can you customize and design as the clients' requirement?
XGMA will try its best to meet all kinds of clients' special requirements. And for new products that have not been into the market yet, we have our technical team to help the clients. All kinds of attachments such as roll paper clamp, side shifter and so on can be available.


3. How long is the warranty of your products?
All of products are with 1 year / 2000 working hours subject to the first.


4. What's the payment terms do you accept?
Normally we accept 30% deposit, 70%balance before delivery.


5. Delivery date:
If clients need normal products, we will deliver the products within 15days. If clients need customerized products, the delivery date depend on the requirements.
