3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
3ton Forklift with Chinese Xinchai C490BPG engine orange color
Specifications
Brand Name :
YEAWEY
Model Number :
CPCD30
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
3Ton diesel forklift
Engine :
Xinchai C490BPG
Engine power :
40.0 kw
Lift height :
4.5m Triplex mast
Fork Size :
1670X125X45MM
Service weight :
4400 kg
Description

3ton Forklift with Chinese Xinchai C490BPG engine orange color

Main information:

Product name: 3.0Ton diesel counter balance forklift

Engine: CUMMINS QSF2.8t

Transmission: Automatic

Mast type: 3 stage mast 4.5m lifting height

Tires: Solid

Fork: 1220mm

Attachments: Side shift

The higher-end model in of YEAWEY forklift products line, sets new bar in counter balance forklifts. It offers graceful appearance and over 55 improvements of inside and out ergonomic design, enhanced safety and performance while lowering vibration, operating noise and easy to maintain.

Working efficiency improved

Small turning radius makes steering flexible and easy.The truck has fast lifting speed, good gradeability and high efficiency.High working efficiency guarantees the truck could meet the requirements for various kinds of complicated work condition perfectly wherever at port, dock and railway station.

Ergonomic comfort

Perfect shape & position of manual gear level facilitate the drivers’ operation.Independent dual rear lights together with warning light are easy to recognize & maintain.

Large Opening Angle

Enlarged internal space is convenient for engine and transmission box maintenance.

Increased hood opening angle makes maintenance convenient.

Safety step

The new wide-open, non-slip step makes getting in and out easy and safe.

Specification CPC30
1 Fuel model Diesel
2 Load capacity kg 3000
3 Load center mm 500
4 Lift height mm 4500
5 Full free lift height mm 1500
6 Fork dimension mm 1520×125×45
7 Mast tilting angle Deg. 6/12
8 Min.turning radius mm 2400
9 Groud clearance mm 135
10 Overhead guard height mm 2165
11 Front overhang mm 495
12 Max travel speed km/h 19
13 Max lift speed mm/s 480
14 Max.traction power KN 13.5
15 Max. gradeability % 20
16 Total length with fork mm 3820
17 Total length without fork mm 2750
18 Total width mm 1225
19 Mast extended height mm 4265
20 Mast lowered height mm 2060
21 Tyres Front 28x9-15-12PR
22 Type Rear 6.50-10-10PR
23 Wheelbase mm 1700
24 Tread mm 1000/970
25 Service weight Kg 4500
26 Battery V/Ah 12/80
27 Engine model CUMMINS
28 Engine power kw/r.p.m QSF2.8t
29 Transmission Mechanical
30 Work press Mpa 18.5

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color

3ton Forklift with Chinese Xinchai C490BPG engine orange color
