Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
Specifications
Brand Name :
YEAWEY
Model Number :
CDD10
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
1T walkie electric forklift
Load capacity :
1000 kgs*600mm
Lift height :
1600-3000mm mast
Fork length :
1150mm
Battery :
2x12V/80Ah
Service weight :
506KG
Description

2 stage walkie 1Ton electric stacker warehouse use lithium battery

Main information:
Chinese AC controller
2X12V/80Ah lead acid battery forklift
Mast type: 2 stage mast
Lift height: 1600-3000mm
Tires: Solid
Fork: 1150mm

The YEAWEY walkie stackers are tailored towards pedestrian controlled stacking operations with capacities from 1200kg up to 2000kg.
With the mounted long tiller the operator can keep a safe and ergonomic distance while performing his work.
Due to the gentle full proportional lift system, stacking operations becomes safer and faster.
With high quality and state of the art top brand components and technology, the truck competes with other leading brands in the market.

Multi functional handle, integrated with key switch, upright walking button, LCD screen (battery level, working time, fault display), optional turtle speed, simple and comfortable operation;

ItemModel CDDC10-16CDDC10-30
1Power type ElectricElectric
2Drive mode Walkie TypeWalkie Type
3Load capacityQ(Kg)10001000
4Load centerC(mm)500500
5Wheel baseY(mm)11971197
6Self weight with batterykg506566
7Axle load at full load, drive end/bearing endkg711/1294732/1344
8Axle load when unloaded, drive end/bearing endkg368/138411/155
9Tire type Front/Rear Pu solid tirePu solid tire
10Front tire size∅×w(mm)Φ80x70Φ80x70
11Rear tire size∅×w(mm)Φ210x70Φ210x70
12Track width, front wheelsb10(mm)515515
13Track width, rear wheelsb11(mm)530530
14Height-Mast Loweredh1(mm)20551980
15Lift Heighth3(mm)16003000
16Maximum height when fork is liftingh4(mm)20753478
17Min. Fork heighth13(mm)8585
18Overall lengthl2(mm)18581865
19Overall widthb1(mm)800800
20Fork sizes/e/l(mm)65/165/115065/165/1150
21Width over forkb5(mm)350/680350/680
22Min ground clearancem2(mm)2525
23Min. stacking aisle 1000*1200 pallet(1200 cross fork placement)Ast(mm)22382238
24Min. Turning radiusWa(mm)13801380
25Max.walking speedkm/h4/3.54/3.5
26Max. lifting speedm/s0.101/0.0950.101/0.095
27Max. lowing speedm/s0.111/0.1250.111/0.125
28GradeAbility％6/36/3
29Drive brake ElectromagneticElectromagnetic
30Drive motorkw0.750.75
31Lift motorkw2.22.2
32Battery type Lead acidLead acid
33Battery capacityV/Ah2x12/802x12/80
34ChargerV/A24V/10A24V/10A
35DriveControllingType DCDC
36The noise level in the driver's ear according to EN12053dB(A)7575


Warehouse Battery Powered Pallet Stacker 1T Electric Walkie StackerWarehouse Battery Powered Pallet Stacker 1T Electric Walkie StackerWarehouse Battery Powered Pallet Stacker 1T Electric Walkie StackerWarehouse Battery Powered Pallet Stacker 1T Electric Walkie StackerWarehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker

Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker

Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker

Warehouse Battery Powered Pallet Stacker 1T Electric Walkie Stacker
