Specifications
Brand Name :
YEAWEY
Model Number :
CDD20-30
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
2T walkie electric forklift
Load capacity :
2000 kgs*600mm
Lift height :
3000mm mast
Fork length :
1370mm
Battery :
24V/100Ah
Service weight :
850KG
Description

Duplex mast 3m mast 2Ton electric walkie stacker warehouse use lead acid battery

Main information:
Chinese AC controller
24V/100Ah lead acid battery forklift
Mast type: 2 stage mast
Lift height: 3000mm
Fork: 1370mm
Warranty:
The warranty period is 24 months from on board date or 2000 working hours whichever comes first.
During warranty, we offer air delivery of the spare parts within 2 working days.Besides that, we have experienced engineers to check the problems and maintenance.
Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.
Should you have any questions pls feel free to let us know.

Item Model CDD20D-30
1 Power type Electric
2 Operation mode Walking type
3 Rated load kg 2000
4 Load center distance mm 500
5 Tire type (front/ rear) Polyurethane
6 Number of tires 4/1X+1
7 Mast type Duplex mast
8 Standard lifting height mm 3000
9 Height of mast closed mm 2080
10 Mast height during lifting mm 3565
11 Minimum ground clearance of cargo depot mm 85
12 Overall length mm 2030
13 Wheelbase mm 1430
14 Overall width mm 850
15 Track width (front/ rear) mm 490/545
16 Fork specifications mm 1150*190*65
17 Fork side outer distance mm 680/560
18 Turning radius mm 1645
19 Channel width (1200x1000 pallets, 1200 horizontal) mm 2515
20 Travel speed (full load/ no load) km/h 4.0/4.5
21 Lifting speed (full load/ no load) mm/s 80/125
22 Descent speed (full load/ no load) mm/s 160/105
23 Gradient (full load/ no load) % 45453
24 Drive motor power kw 1.5
25 Type of lifting motor DC
26 Lifting motor power kw 2.2/3.0
27 Battery voltage/ capacity v/ah 24/100
28 Battery weight kg 75
29 Service weight (incl. battery) kg 850
30 Steering type Manual operation
31 Parking brake type Electromagnetism
32 Parking brake operation mode Handle operation


3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers

3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers

3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers

3m Mast 2Ton Electric Walkie Stacker Warehouse Fully Powered Stackers
