4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
Specifications
Brand Name :
YEAWEY
Model Number :
CPCG40
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
7000-9500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
4.0 Ton gasoline lift truck
Engine :
NISSAN GK25 engine
Lift height :
6000mm
Mast type :
Triplex FFL mast
Fork Size :
1520mm length
Service weight :
5150KG
Description

4000kgs CPCD40 4 Ton gasoline powered forklift truck triplex 6m mast

Main information:
Product name: 4.0Ton gasoline powered forklift
Engine: Chinese GQ-4Y diesel engine
Transmission: Automatic
Mast type: 3 stage mast 6000m lifting height
Tires: pneumatic
Fork: 1.52m
Attachments: Side shift, long forks


The higher-end model in of YEAWEY forklift products line, sets new bar in counter balance forklifts. It offers graceful appearance and over 55 improvements of inside and out ergonomic design, enhanced safety and performance while lowering vibration, operating noise and easy to maintain.

Working efficiency improved

Small turning radius makes steering flexible and easy.The truck has fast lifting speed, good gradeability and high efficiency.High working efficiency guarantees the truck could meet the requirements for various kinds of complicated work condition perfectly wherever at port, dock and railway station.

Ergonomic comfort

Perfect shape & position of manual gear level facilitate the drivers’ operation.Independent dual rear lights together with warning light are easy to recognize & maintain.

Full Hydraulic Steering System

Offer lighter, more flexible steering, with reduced turning radius and handles driving large vehicle like a small vehicle.

Workspace increased

Space around foot is effectively increased through up steering unit and using suspension type inching.

The operation space is enlarged by heightened overhead guard and using large arc shape of the overhead guard's front leg.

Wide-angle Rear-View Mirror

Provides more comprehensive rear viewfor enhanced safety.

Specification CPCG40
1 Fuel model Gasoline
2 Load capacity kg 4000
3 Load center mm 500
4 Lift height mm 6000
5 Full free lift height mm 1800
6 Fork dimension mm 1520×150×45
7 Mast tilting angle Deg. 6/12
8 Min.turning radius mm 2800
9 Groud clearance mm 135
10 Overhead guard height mm 2230
11 Front overhang mm 500
12 Max travel speed km/h 18.5
13 Max lift speed mm/s 420
14 Max.traction power KN 20
15 Max. gradeability % 20
16 Total length with fork mm 4105
17 Total length without fork mm 3035
18 Total width mm 1230
19 Mast extended height mm 4270
20 Mast lowered height mm 2190
21 Tyres Front 250-15- 12PR
22 Type Rear 7.00-12-12PR
23 Wheelbase mm 1900
24 Tread mm 1160/1065
25 Service weight Kg 5300
26 Battery V/Ah 12/100
27 Engine model Chinese GQ-4Y diesel engine
28 Engine power kw/r.p.m 34
29 Transmission Mechanical or Automatic
30 Work press Mpa 18.5

4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift

4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift


4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift

4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift

4 Ton Gasoline Powered Forklift 4000kgs CPCD40 6m Mast Counterbalance Lift
