Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Japanese Forklift Mitsubishi 2.5 Ton 2500kgs Diesel Powered Forklift
Specifications
Brand Name :
YEAWEY
Model Number :
CPCD25
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
2.5T diesel forklift truck
Load capacity :
2500 kgs
Lift height :
3 stage 4.5m mast
Mast type :
container mast
Fork Size :
1220X122X40MM
Service weight :
4050 kg
Engine :
MITSUBISHI S4S
Cabin :
Closed cabin with heater
Description

Japanese MITSUBISHI diesel engine 2.5 ton diesel powered forklift truck cabin heater

Main information:

Product name: 2.5Ton diesel counter balance forklift

Engine: Japanese MITSUBISHI S4S diesel engine

Transmission: Automatic

Mast type: 3 stage mast 4.5m lifting height

Tires: Pneumatic

Fork: 1220mm

Attachments: Closed cabin with heater

The higher-end model in of YEAWEY forklift products line, sets new bar in counter balance forklifts. It offers graceful appearance and over 55 improvements of inside and out ergonomic design, enhanced safety and performance while lowering vibration, operating noise and easy to maintain.

Working efficiency improved

Small turning radius makes steering flexible and easy.The truck has fast lifting speed, good gradeability and high efficiency.High working efficiency guarantees the truck could meet the requirements for various kinds of complicated work condition perfectly wherever at port, dock and railway station.

Ergonomic comfort

Perfect shape & position of manual gear level facilitate the drivers’ operation.Independent dual rear lights together with warning light are easy to recognize & maintain.

Steer Axle

Oscillating steer axle allows either wheel to step over obstacles keeping the machine and load level. Flirtation drive& steer tires provide excellent traction and stability.The steering angle is from 54° to 78'with very small turning radius.

Suspension Seat (Optional)

Optional TOYOTA suspension seat with tilting and sliding adjustment absorbs vibrations, improving comfort and safety.

New design of key parts

The optimal design of key parts like frame, mast, overhead guard and steering axle improve the whole truck's safety and reliability.

Specification CPCD25
1 Fuel model Diesel
2 Load capacity kg 2500
3 Load center mm 500
4 Lift height mm 4500
5 Full free lift height mm 1500
6 Fork dimension mm 1220×122×40
7 Mast tilting angle Deg. 6/6
8 Min.turning radius mm 2240
9 Groud clearance mm 120
10 Overhead guard height mm 2140
11 Front overhang mm 485
12 Max travel speed km/h 19
13 Max lift speed mm/s 550
14 Max.traction power KN 12.3
15 Max. gradeability % 20
16 Total length with fork mm 3610
17 Total length without fork mm 2540
18 Total width mm 1160
19 Mast extended height mm 5720
20 Mast lowered height mm 2060
21 Tyres Front 7.00-12-12PR
22 Type Rear 6.00-9-10PR
23 Wheelbase mm 1600
24 Tread mm 970/970
25 Service weight Kg 4050
26 Battery V/Ah 12/80
27 Engine model MITSUBISHI S4S diesel engine
28 Engine power kw/r.p.m 34 kw
29 Transmission Mechanical or Automatic
30 Work press Mpa 18.5
