2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
Specifications
Brand Name :
YEAWEY
Model Number :
CQD16J
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
3.0T Electric Tow Tractor (load bearing)
Load capacity :
3000 kgs
Battery :
24V/210Ah
Service weight :
750 kgs
Controller :
ZAPI
Motor :
AC
Description

Traction weight: 2000/3000KG

YEAWEY Tow tractor usually used for material traction in airports, stations, workshops and warehouses. It also can used as an important transportation tool for baggage traction, regional logistics and workshop circulation.

The truck is designed as compact structure, good maneuverability, and suitable for narrow-area operation. It's powerful, stable and reliable in operation.

Rubber shock absorption are adopted for both front and rear axles, greatly improving the driving experience and effectively reducing the vehicle vibration on the operator.

Advantage:

  • American CURTIS brand drive control system
  • Multifunctional integrated handle
  • Electronic steering, portable
  • Integrated brand low noise hydraulic pump
  • AC drive, brushless, motor maintenance free
  • Electromagnetic and regenerative braking system
  • Drive shock absorption system / pedal, handle shock absorption
  • Inductive proximity switch

Safety:

  • Curve automatic deceleration device
  • Drive stepless speed regulation
  • Controller multiple automatic protection system
  • Emergency reverse anti-collision/ emergency braking device
  • Cylinder safety shut-off valve
Item Name Electric tow tractor
1 Model QDD30C
2 Traction weight kg 3000
3 Traction type Load bearing type
4 Max. lifting height mm 365
5 Height of bearing shaft head from the ground mm 195
6 Tire configuration Polyurethane solid tire
7 Outside width of fork leg mm 560
8 Full length (including fork pedal retraction) mm 1780
9 Overall width mm 850
10 Overall height mm 1500
11 Wheelbase mm 1245
12 Turning radius (outer pedal retracted) mm 1545
13 Max. driving speed km/h 4.0/5.0
14 Gradeability % 5月8日
15 Total weight kg 750
16 Drive wheel mm Φ230*75
17 Front wheel mm Φ150*90
18 Balance wheel mm Φ130*55
19 Battery capacity v/ah 24/210
20 Battery charger v/a 24/30
21 Drive motor kw 1.6
22 Lifting motor kw 2.2
23 Travel speed regulation mode Hall accelerator

2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type

2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type



2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type

2000kg 3000kg QDD30C 3.0T Electric Tow Tractor (load bearing) standing type
