QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
Specifications
Brand Name :
YEAWEY
Model Number :
QDD40/60/80
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
4T Seated Electric Tow Tractor
Controller :
ZAPI brand
Battery :
48V/280Ah
Service weight :
210-550kgs
Traction weight :
4-8Ton
Color :
Blue or yellow
Description

Main information:

Curtis controller

AC lift and drive motor

Lead acid or lithium battery

Seating type

YEAWEY Tow tractor usually used for material traction in airports, stations, workshops and warehouses. It also can used as an important transportation tool for baggage traction, regional logistics and workshop circulation.

The truck is designed as compact structure, good maneuverability, and suitable for narrow-area operation. It's powerful, stable and reliable in operation.

Rubber shock absorption are adopted for both front and rear axles, greatly improving the driving experience and effectively reducing the vehicle vibration on the operator.

Advantage:

  • Electronic power steering, portable and mute
  • Bridge drive unit
  • AC drive, brushless, motor maintenance free
  • American CURTIS drive controller
  • Electromagnetic and regenerative braking system
  • Safety seat
  • Forward and backward fine adjustment
  • Simple operation and flexible steering

Multifunction instrument

Standard multifunction instrument todisplay battery status, travel speed, faultcode and so on.

Blue light
The standard blue light is not only activatedautomatically when the truck is driving forward. but also turns.

Three traction couplers
The reinforced couplers can be set as three heights so as to ensure reliable connectionto various trailers to meet different needs of working conditions.

Item Model QDD40 QDD60
1 Power type Electric Electric
2 Operation mode Seated type Seated type
3 Traction weight kg 4000 6000
4 Tire type front / rear Rubber solid tire Rubber solid tire
5 Front wheel 3.50-5 3.50-5
6 Rear wheel 4.00-8 4.00-8
7 Min. ground clearance mm 95 95
8 Overall length mm 1720 2020
9 Wheelbase mm 1040 1325
10 Overall width mm 850 985
11 Track width (front/ rear) mm 760 870
12 Turning radius mm 1400 1525
13 Travel speed (full load/ no load) km/h 4.5/ 7 ‘8/15
14 Gradient (full load/ no load) % ‘3/10 ’6/12
15 Drive motor power kw 2 5
16 Battery voltage/ capacity v/ah 24/240 48/280
17 Service weight (incl. battery) kg 210 550
18 Steering type 900 1200
19 Service brake type Electric steering Electric steering
20 Parking brake type Mechanical/ hydraulic Mechanical/ hydraulic

QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8TQDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8TQDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8TQDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8TQDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8TQDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T

QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T



QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T

QDD40/60/80 Seated Electric Tow Tractor Traction weight: 4T-8T
