Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
Specifications
Brand Name :
YEAWEY
Model Number :
CTD20
Certification :
CE ISO，SGS
Place of Origin :
China
MOQ :
1 unit
Price :
6000-7500 usd
Payment Terms :
L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
5-8 working days
Packaging Details :
Plastic bag
Product name :
20T standing electric straddle stacker
Load capacity :
2000kgs*600mm
Lift height :
3000mm mast
Fork length :
1220mm
Battery :
24V/210Ah
Service weight :
730
Description

Duplex mast 3m mast 2Ton electric standing straddle stacker warehouse use lead acid battery

Main information:
Chinese AC controller

Load capacity: 2000kg

Standarding type
24V/210Ah lead acid battery forklift
Mast type: 2 stage mast
Lift height: 3000mm
Fork: 1200mm

The new Yeawey battery powered MINI electric pallet truck is designed under the current industrial trend of light duty with a target to minimize the cost in manufacturing.

It continues to offer the function and solution usually for high-end electric pallet trucks including Can-bus Communication, Fault Code, Battery Discharging Indicator, Drive with the tiller in vertical position, Electric lift and lower control etc.


Warranty:
The warranty period is 24 months from on board date or 2000 working hours whichever comes first.
During warranty, we offer air delivery of the spare parts within 2 working days.Besides that, we have experienced engineers to check the problems and maintenance.


Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.
Should you have any questions pls feel free to let us know.

Item Model CTD20-30
1 Power type
2 Drive mode Standing Type
3 Load capacity Q(Kg) 2000
4 Load center C(mm) 500
5 Wheel base Y(mm) 1468
6 Self weight with battery kg 1142
7 Tire type Front/Rear Pu solid tire
8 Front tire size ∅×w(mm) Φ80x70
9 Rear tire size ∅×w(mm) Φ230x75
10 Track width, front wheels b2(mm) 1390
11 Track width, rear wheels b3(mm) 658
12 Height-Mast Lowered h1(mm) 2095
13 Lift Height h(mm) 3000
14 Maximum height when fork is lifting h2(mm) 3975
15 Handle Height h5(mm) 1476
16 Min. Fork height h3(mm) 40
17 Overall length Pedal Closed L(mm) 2155/2570
18 Overall width b1(mm) 1520
19 Fork size s/e/l(mm) 40/122/1070
20 Width over fork b5(mm) 680
21 Min ground clearance m2(mm) 45
22 Min. stacking aisle 1000*1200 pallet(1200 cross fork placement) Ast(mm) 2770
23 Min. stacking aisle 1000*1200 pallet(1200 placed along forks) Ast(mm) 2770
24 Min Turning Radius When Pedal Closed Wa(mm) 1805
25 Max.walking speed km/h 5.5/5
26 Max. lifting speed m/s 0.130/0.075
27 Max. lowing speed m/s 0.082/0.123
28 GradeAbility ％ 10/4
29 Drive brake Electromagnetic
30 Drive motor kw 1.5
31 Lift motor kw 2.2
32 Battery type
33 Battery capacity V/Ah 24/210
34 Charger V/A 24/30
35 DriveControllingType alternating current
36 The noise level in the driver's ear according to EN12053 dB(A) 75

Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2TonStanding Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2TonStanding Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2TonStanding Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2TonStanding Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton


Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton

Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton

Standing Electric Straddle Stacker Warehouse Counterbalance Pallet Stacker 2Ton
