25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
Specifications
Brand Name :
GPRO
Model Number :
GP28DCS
Certification :
ISO,CE Certification
Place of Origin :
Jiangsu of China
MOQ :
1 SET
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
300 Set / Month
Delivery Time :
15 - 20 working day
Packaging Details :
Plywood or Plastic packing
Output Power :
20KW 25KVA
Frequency :
50/60HZ
Voltage :
220v - 690v optional
Engine :
Cummins, Perkins, Deutz, FPT, Chinese brand for optional
Alternator :
Stamford, Meccalte, Leroy Somer, Marathon, Wattek for optional
Controller :
Deepsea, Smartgen, Harsen for optional
MCCB :
ABB or Delixi
Cooling system :
Water cooled
Genset type :
Open type, Silent type, Container type, Trailer type for optional
ATS :
Optional
Description

25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine

Model GP28DCS
Rated output(KW) 20kw/25kva
Max.output(KVA) 22kw/28kva
Frequency(HZ) 50
Rated voltage(V) 230/400
Rated current(A) 54.1
Engine Model Cummins 4B3.9-G1
Cylinder number 4
bore*stroke(mm) 100*115
Fuel consumption(g/kw.h)at full load 230
Compression ratio 19:01
Starting system Electric starter
Rated Rotation Speed(rpm) 1500
Power factor Cos% 0.8
Insulation grade H
Excitation mode self-excitation and cinstant voltage(AVR)
Diamension(L*W*H) 2190*1050*1340
net weight(KG) 1000

25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine

ATS-Automatic Transfer Switch, when the city power supply failure, the genset will be running automatically within few minutes.

Our normal ATS is bulit inside,but outside ATS box is optional

25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine

Testing Items of GPRO Genset:
1) Parts fault testing
2) Fue tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insultion testing
6) Noise testing
7) Loading testing: All qualified generator sets are subjected to a comprehensive performance test which inclides 0% load, 25% load, 50% load, 75% load, 100% load and 110% load and to check, verify that all control systems, alarm and shut-own protection.

Guarantee:
1) Guarantee Period: One year or 1000 running hours, depends on whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.


If you are interested, please contact with us at any time!

25kva Super Silent Generator Set By Cummins / FAWDE / Racardo Diesel Engine
