1000A Oscilloscope Current Clamp , Q125 Current Clamp For Multimeter
1000A Oscilloscope Current Clamp , Q125 Current Clamp For Multimeter
Specifications
Brand Name :
HNMC
Model Number :
Q125
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Delivery Time :
4-8weeks
Packaging Details :
wooden package
Size :
94mm×210mm×22mm
Installation method :
clamp type
Characteristic :
apply to test on line below 1000A
Ratio :
1000: 1 or 2000:1 (customized)
Accuracy class :
0.2%, 0.5%, 1%
Primary current :
0 - 3000A AC
Description

​

AC Current Probe in Digital Energy Meters Accuracy Class 0.5

Introduction

The model Q125 current clamp on measuring instrument can be used for a current vector for the copper bar or the power aluminum bus bar on-line detection.

Applications

1. Electric energy meter calibrator (on site)

2. Double clamp type ground resistance tester

3. Double clamp type phase volt-ampere meter

4. Digital multi-meter

5. Multi-function energy meter

6. Oscilloscope

7. Power quality analyzer

8. Matched instruments

9. Calibration instrument on site

Parameter

Electrical parameters
Ratio 1000: 1 or 2000:1 (customized)
Accuracy class 0.2%, 0.5%, 1%
Primary current 0 - 3000A AC
Secondary current 0 - 5A AC (customized)
Max. Cont. Input current 3600A
Over voltage category CAT III 600 V
Output signal (AC current) 500mA,1A,5A AC at nominal input current
Electrical parameters - continued 　
Output signal (AC voltage) 333mV,500mV,1V,5V AC at nominal input current
Frequency range 40Hz-2000Hz
Dielectric strength 3KV 50Hz/60Hz at 1 minute
Temperature range -20°C to +55°C
Output 2.5 meter cable with D01 connector
Max. voltage not insulated conductors 600 V
Standard EN 61010-1, EN 61010-2-032, IEC60044-1
Installation Clamp type
Output mode Lead output (2.5m)
Mechanical parameters
Dimensions (L x W x H) (mm) 116 x 327 x 35
Weight (g) 1200
Holding wire diameter (mm) φ120 x 50
Max. jaw opening (mm) 50
Jaw color White
Material PC+ABS+Polycarbonate, UL94 V0
