Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles
Specifications
Brand Name :
RFan
Place of Origin :
China
MOQ :
1000
Price :
negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1KK/M
Delivery Time :
5-10days
Packaging Details :
1000/Bag
Keywords :
NTC sensor
Material :
Epoxy and Metal
Customized :
Available
Rohs Compliant :
Yes
Withstand Voltage :
≥1500VAC
Wire Length :
Customized To Your Demands
Description

NTC Temperature Sensor For Intelligent Disinfection Cabinets And New Energy Vehicles

Features

1. OT and UT size can be customized according to client's requirement,manytype and size to choice,esay to install.

2. Operation temperature range:-50~150℃

3. Thermal time constant 5S

4. Water proof Grade:IP66

5. Voltage ressistace test with AC1500V 30S

6. The wire and terminal can be customized according to client's requrment

Applications

Suitable for temperature detection and protection ofvarious intelligent

small household appliances,disinfection cabinets,yogurt machines,heaters coffee machines,andnew energy vehicles.

Appearance and size (mm)

Customized NTC Sensor For Disinfection Cabinets And New Energy Vehicles

Appearance specifications

NO Material name Specifications / models Quantity
L1 Shell Wiring ring5*8*20(φ4.0) 1pcs
L2 Thermistor 10K 39501% 1pcs
L3 Resin Black epoxy-coated resin 0.3G
L4 wire 26#1332 Black 200℃ L160mm 1pcs
L5 Tail Tail tin 3mm
L6

Electrical Characteristics

NO project Mark Test condition Minimum value Normal value Maximal value Unit
3-1 Resistance value of 25℃ Ta=25±0.05°CPt三0.1mw 9.9 10.0 10.1 kQ
3-2 Resistance value of 50℃ Ta=50±0.05°℃Pt三0.1mw 3.588 / kQ
3-3 B value R25750 / 3950 K
3-4 Thermaldissipation coefficient Ta=25±0.5℃ 5 / / mw/℃
3-5 Time constant Ta=25±0.5℃ / / 15 sec
3-6 Insulation resistance / 500Vdc 100 / /
3-7 Voltage ressistace test / 1500V AC,I=0.5mA 60 / s
3-8 Temperature Range / -40 / +125 ℃
