MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass
MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass
MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass
MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass
Specifications
Brand Name :
RFan
Model Number :
MF58
Certification :
UL.TUV.ROHS
Place of Origin :
China
MOQ :
2000PCS
Price :
0.2-0.6
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1KKpcs/month
Delivery Time :
5-7days
Packaging Details :
1000/Bag
Cable :
UL4411# 24AWG
Feature :
Small Size, Strong Power
Resistance Value :
2K-200K
Thermistor :
Power NTC Thermistor
Operating Temperature :
-40℃~125℃
Length :
5mm
Thermal Time :
55/70/90sec
Ntc Thermistor :
MF74 25A NTC Negative Temperature
Transport Package :
Carton Packing
Type :
Chip NTC Thermistor
Description

MF51 10K 3435 3% Temperature-Measurement Chip In Glass NTC Thermistor NTC Thermistor

Negative temperature coefficient (NTC)thermistor

MF51 Temperature-Measurement chip in glass NTC Thermistor series

Applications

◎Air-Conditioner.Heating Apparatus

◎Electric Thermometer

◎ Liquid leve sensor

◎Automoblie electronic Electric table-board

Characteristic

◎ Small size

◎ High testing precision

◎ Fast response

◎ Good quality ofcoherence and interchange

◎ It can be used in such worse environment as high temperature and humdity etc.

Dimensions(mm)

MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass

Normal dimension table

Part No D H L d
MF51-A 2.0±0.2 3.8±0.5 65±2.5 0.3±0.02
MF51-B 1.6±0.2 3.2±0.5 65±2.5 0.25±0.02
MF51-C 1.2±0.2 2.4±0.5 65±2.5 0.20±0.02

Main Techno-Parameter

型号 Part No

耗散系数

(mw/0℃)

Dissi.Coef

(mw/℃)

热时间常数(S)

Thermal time

Constant(S)

最大功耗@25℃

Pmax(mW)
MF51-A 约1.4 约14 50
MF51-B 约0.9 约7 35
MF51-C 约0.75 约5 15

型号 Part No 标称阻值R₂5

B值(25/85℃)

B Value(25/85℃
Rated Resistance R₂s
R25(KQ)

精度

Tolerance

 K

精度

Tolerance

常规 型号

 MF51□□□3435 2 20

±1%

±2%

±3%

±5%

 3435

±1%

±2%
MF51□□□3450 2~10 3450
MF51□□□3750 8~10 3750
MF51□□□3950 10～50 3950
MF51□□□4150 50～100 4150
MF51□□□4200 100～350 4200
MF51□□□4350 870~980 4350
MF51□□□4450 1000~1500 4450
特殊 型号 MF51□2.186K□3420 R25=2.186 R0=6

±2%

±3%

±5%

 3420 (B0/100=3390)

±1%

±2%
MF51□5.369K□3480 R25=5.369 R0=15 3480 (B0/100=3450)
MF51□49.12K□3992 R25=49.12 R100=3.3 3992(B0/100=3970)
MF51□98.63K□4066 R25=98.63 R200=0.55 4066(B100/200=4300)
MF51□231.4K□4240 R25=231.4 R200=1 4240(B100/200=4537

MF51 NTC Thermistor 10K 3435 3% Temperature Measurement Chip In Glass
