200m Ground Water Level Detector Steel Water Level Meters Ruler
200m Ground Water Level Detector Steel Water Level Meters Ruler
200m Ground Water Level Detector Steel Water Level Meters Ruler
200m Ground Water Level Detector Steel Water Level Meters Ruler
200m Ground Water Level Detector Steel Water Level Meters Ruler
200m Ground Water Level Detector Steel Water Level Meters Ruler
Specifications
Brand Name :
PQWT
Model Number :
200m
Place of Origin :
China
Product name :
200m Water level meter
Detection depth :
200 meters
Description

PQWT-200m Water Well metal level transmitter oil water liquid level meter with indicator

The steel ruler water level gauge provides the most accurate way to measure water levels, used to measure the water level in wells, boreholes and water pipes, particularly suitable for the observation of groundwater level in hydro power projects and artificial inspection of dam body infiltration line. The instrument can be used during construction, but also as a long-term safety monitoring with the project, complies with earth dam safety monitoring technical specifications.

Users must pay attention to two points:

A) When the probe contacts come into contact with the water, the sounder will sound, the indicator and the voltmeter pointer start to working. At this point should be slowly put steel ruler cable, in order to carefully find the pronunciation or indicate the exact location of the moment.

B) The accuracy of the reading depends on the timely determination of the buzzer and indicating the starting position.The accuracy of the measurement and the operator's proficiency should be repeated practice and operation.

Main technical indexes

Specification 30 50 100 150 200 300 500
Measurement dept(m) 0~30 0~50 0~100 0~150 0~200 0~300 0~500
Minimum reading(mm) 1.0
Repetitive reading(mm) ±2.0
Operating voltage (V) DC=9
200m Ground Water Level Detector Steel Water Level Meters Ruler200m Ground Water Level Detector Steel Water Level Meters Ruler200m Ground Water Level Detector Steel Water Level Meters Ruler
