900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing
Specifications
Brand Name :
Meiko
Model Number :
SM-900
Certification :
ISO9001
Place of Origin :
ANHUI, CHINA
MOQ :
50pcs
Price :
USD1-USD10 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100000pcs per month
Delivery Time :
7 days
Packaging Details :
Carton Size: L35x25x15cm
Material :
3mm Carbon Steel, Neodymium Magnet
Coating :
Black Oxidation Treatment
Veritical Power Capacity :
900KG, 1000KG Force
Dimension :
L280x60x40mm
N.W. :
3KG per piece
Description

900KG Box Magnet is a regular magnetic box size for precast formwork construction, both of wooden and steel side mould, composed with carbon box shell and a neodymium magnetic system.

It can be activated by simply pressing down the button by the hand or foot. To deactivate them, the magnets are easily released by steel lever (to pull the button on). In the inactive position, the shuttering magnets can be easily removed from the table form. The precast concrete magnets could be used alone or connected with adpator to fix the formwork. Normally 900Kg vertical force box magnet is perfectly suitable for 60-90mm thickness wall panel production.

900KG, 1Ton Type Box Magnets For Precast Tilting Table Mould Fixing

KEY BENEFITS OF Precast Shuttering Magnet:
1. Reducing the complexity and time of the installation of formwork (up to 70%).
2. Universal use for mass production of concrete products, and piece products of all forms on the same steel table.
3. Eliminates the need for welding, shuttering magnets does not damage the steel table.
4. Makes it possible to produce radial products. Formwork Shuttering Magnet for Precast Plant
5. A small cost of a set of magnets. The average payback of about 3 months.
6. The main advantage of the shuttering magnets is that you do not need to have a lot of different forms for different products, you need to have a set of magnets, adapters for different height boards and steel table. Precast Concrete Shuttering Magnet Box 900kg

Type L W H Screw Force N.W.
mm mm mm 　 KG KG
SM-450 170 60 40 M12 450 1.8
SM-600 170 60 40 M12 600 2.3
SM-900 280 60 40 M12 900 3.0
SM-1350 320 90 60 M16 1350 6.5
SM-1800 320 120 60 M16 1800 7.2
SM-2100 320 120 60 M16 2100 7.5
SM-2500 320 120 60 M16 2500 7.8

We, Meiko Magnetics, are professional in all kinds of magnetic solutions for precast concrete industry. You can find all your standard requirements or customized magnetic system here for precast.
