Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings
Specifications
Brand Name :
AWX
Model Number :
61806 61807 61805 60808 ZZ
Certification :
CE/ISO
Place of Origin :
china
MOQ :
10pcs
Supply Ability :
1000000
Delivery Time :
within 7days
Packaging Details :
carton
Model No :
4217 ATN9
Size :
85*150*36mm
Static state Cor :
99.96
Vibration Acceleration :
Z Z1 Z2 Z3 Z4
Seals Type :
Open
Sample :
Avaliable
Vibration Tolerance :
VV1 V2 V3 V4
Outline size / chamfer :
2
Radial Clearance :
C2 Co C3 C4 C5
Description

Product Description:

Thin wall bearings are designed with a minimal cross-section to save space and reduce weight. They are commonly used in applications with limited space and where high levels of precision are required. These bearings are typically made from high-quality materials such as stainless steel, chrome steel, or ceramic to provide durability and reliable performance. Thin wall bearings are typically used in industries such as robotics, medical devices, aerospace, and automotive. They are available in various types including deep groove, angular contact, and four-point contact to suit different applications. These bearings are designed to provide smooth and quiet operation while handling radial and axial loads.

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall BearingsEfficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall BearingsEfficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Features:

1.Minimal cross-section: Thin wall bearings have a compact design with a minimal cross-section, making them ideal for applications with limited space.

2.Lightweight: These bearings are lightweight, which helps reduce the overall weight of the machinery or equipment they are used in.

3.High precision: Thin wall bearings are designed to provide high levels of precision and accuracy, making them suitable for applications that require precise positioning and smooth operation.

4.Durability: Thin wall bearings are typically made from high-quality materials such as stainless steel, chrome steel, or ceramic, ensuring durability and long service life.

5.Low friction: Thin wall bearings are designed to minimize friction, resulting in smooth and efficient operation with minimal wear and tear.

6.Versatile: Thin wall bearings are available in various types, such as deep groove, angular contact, and four-point contact, to accommodate different load types and mounting configurations.

7.Quiet operation: Thin wall bearings are engineered to operate quietly, providing a comfortable working environment in applications where noise levels need to be minimized.

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall BearingsEfficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Technical Parameters:

Bearing Designations Boundary Dimensions(mm) Basic Load Rating(KN) Limiting Speed(r/min) Weight
d D B Cr Cor Grease Oil (kg)
61819 95 120 13 19.8 21.3 4500 5600 0.27
61820 100 125 13 20.1 22 4300 5300 0.28
61821 105 130 13 20.3 22.7 4000 5000 0.3
61822 110 140 16 28.1 30.7 3800 5000 0.5
61824 120 150 16 28.9 32.9 3400 4300 0.54
61826 130 165 18 37.9 42.9 3200 4000 0.736
61828 140 175 18 38.2 44.3 3000 3800 0.784
61830 150 190 20 49.1 57.1 2800 3400 1.114
61832 160 200 20 49.6 59.1 2600 3200 1.176
61834 170 215 22 61.5 73.3 2200 3000 1.545
61836 180 225 22 62.3 75.9 2000 2800 1.621
61838 190 240 24 75.1 91.6 1900 2600 2.1
61840 200 250 24 74.2 91.2 1800 2400 2.178
61844 220 270 24 76.4 97.8 1700 2200 2.369
61848 240 300 28 83.5 108 1500 1900 4.5
61852 260 320 28 95 128 1300 1700 4.85
61856 280 350 33 135 178 1200 1600 7.4
61860 300 380 38 162 222 1100 1400 11
61864 320 400 38 168 235 1000 1300 11.8
61868 340 420 38 174 265 1000 1300 12
61872 360 440 38 182 285 1100 1400 11.8
61876 380 480 46 235 348 800 1000 20.5
61880 400 500 46 247 405 950 1200 21.7
61884 420 520 46 251 425 950 1180 22
61888 440 540 46 251 425 950 1180 23.6
61892 460 580 56 322 538 860 1000 33.5
61896 480 600 56 315 610 870 1100 36

Company Profile:

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall BearingsEfficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall BearingsEfficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Applications:

Thin-wall deep groove ball bearings are widely used in various industries such as motor, generator, agriculture, material transportation, industrial gearbox, food and beverage, industrial fan, vehicle, and medical apparatus and instruments. The use of thin wall bearings in these industries has become very common nowadays.

These industries have greatly improved their capabilities and efficiency in performing their respective tasks because of the utilization of thin wall bearings. For instance, motors and generators require bearings to maintain smooth and efficient operation while agricultural equipment, such as tractors and combines, depend on bearings to ensure the effective harvesting of crops. Similarly, industrial fans and gearboxes rely on bearings to achieve proper speed control and torque management.

The utilization of thin wall bearings has contributed greatly to the overall improvement of these industries in terms of productivity and functionality. In the medical field, thin wall bearings are utilized in equipment such as MRI machines and ultrasounds, ensuring that patients receive the highest standard of care possible.

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

Packing and Shipping:

Product Packaging:

The thin wall bearings are packaged in a sturdy cardboard box to protect them during shipping and storage. Each bearing is individually wrapped in a plastic bag to prevent any damage or contamination during transportation.

Shipping:

Our thin wall bearings are shipped via a reputable courier service to ensure fast and reliable delivery to our customers. We take great care in packaging and labeling each shipment to ensure that it arrives in good condition and is easy to identify.

Efficient Operation ZZ Series Bearings For Robotic Arms Metric Sizes 61810 61811 61813 61814 61815 Thin Wall Bearings

FAQ:

Q:What's your after-sales service and warranty?
A: We promise to bear the following responsibilities when defective products were found:
1. Replacements would be sent with goods of your next order;
2. Refund for defective products if customers require.

Q:Do you accept ODM&OEM orders?
A: Yes, we provide ODM&OEM services to worldwide customers, we also customize OEM box and packing as your requirements.

Q:What's the MOQ?
A: MOQ is 10pcs for standardized products; for customized products, MOQ should be negotiated in advance. There is no MOQ for sample orders.

Q:How long is the lead time?
A: The lead time for sample orders is 3-5 days, for bulk orders is 5-15 days.

Q:Do you offer free samples?
A: Yes we offer free samples to distributors and wholesalers, however customers should bear freight. We DO NOT offer free samples to end users.

Q:How to place order?
A: 1. Email us the model, brand and quantity,shipping way of bearings and we will quote our best price for you;
2. Proforma Invoice made and sent to you as the price agreed by both parts;
3. Deposit Payment after confirming the PI and we arrange production;
4. Balance paid before shipment or after copy of Bill of Loading.
