Product Introduction

Key Features

Slow Down Function

• The primary function of this rotary damper is to slow down the closing process of the toilet seat. It eliminates the noisy and often jarring slam that is common with traditional toilet seats. The slow-down action is achieved through a hydraulic system that gradually reduces the speed of the seat as it approaches the closed position. This not only adds a touch of elegance and refinement to the overall operation but also significantly reduces the risk of pinched fingers and damage to the toilet bowl or seat.
• The smooth and quiet closing motion creates a more pleasant and peaceful bathroom environment, especially in shared or multi-story residences where noise can be a concern. It also helps in maintaining the integrity of the toilet seat and its hinges, as it minimizes the stress and impact associated with sudden closures.

Hydraulic Adjustable Feature

• The hydraulic adjustable rotary damper hinge allows users to customize the closing speed and resistance according to their specific preferences and the requirements of the toilet seat. The adjustable range provides flexibility in handling different seat weights, materials, and designs. For example, a heavier wooden toilet seat may require a higher damping force compared to a lighter plastic one. With this adjustable feature, users can easily fine-tune the damper to achieve the perfect balance between a gentle closing and a secure seat position.
• The hydraulic adjustment mechanism is user-friendly and can be easily operated without the need for any specialized tools. This makes it convenient for both initial installation and any subsequent adjustments that may be necessary over the life of the toilet seat.

Durable and Reliable Construction

• Built with high-quality materials, this damper hinge is designed to withstand the rigors of daily use in a bathroom environment. The hydraulic components are made from corrosion-resistant materials to ensure long-term performance and reliability. The overall construction is robust enough to handle repeated opening and closing cycles without losing its effectiveness.
• The materials used also contribute to the hygiene of the product. They are easy to clean and resistant to the growth of bacteria and mold, which is essential in a bathroom setting where cleanliness is of utmost importance.

Compact and Space-Saving Design

• The rotary damper hinge has a compact design that allows it to be easily integrated into the existing structure of the toilet seat without taking up excessive space. It is designed to fit most standard toilet seat hinge configurations, making it a versatile solution for a wide range of toilet models. The space-saving design ensures that the overall aesthetics of the toilet are not compromised, and it blends in seamlessly with the surrounding fixtures.

Specification Details

• Model No.	Torque Range	Operation Angle	Minimum Working Angle	Use Temperature	Body Material	Rotary Shaft Material	Use Oil	Lifted Open Force	Life cycle
  HIE-T095A	5-30KGF.CM	110°	30°-50°	-5~+50°	PBT/PA66	PA66/Zinc ALloyd	Silicone Oil	N/A	50000 time

Application Scenarios

• Ideal for use in residential bathrooms, where it provides a more comfortable and quiet toilet seat closing experience. It is especially beneficial in homes with children or elderly residents, where safety and noise reduction are important considerations.
• Suitable for commercial bathrooms in hotels, restaurants, and public facilities. The adjustable damping force and durable construction make it suitable for heavy-use environments where toilet seats need to withstand frequent opening and closing.

Installation and Maintenance

• Installation: The installation process is straightforward. The damper hinge is attached to the toilet seat hinge using simple screws or clips, depending on the specific model. Clear installation instructions are provided to guide users through the process.
• Maintenance: Regular inspection of the damper for any signs of wear, such as leakage of hydraulic fluid or loose parts, is recommended. If any issues are detected, the damper can be easily replaced. Cleaning the damper with a mild detergent and a soft cloth is sufficient to keep it in good working condition.
