Product Introduction

Key Features

Decorative Screw Cover Design

• The damper features a decorative screw cover, which serves a dual purpose. Firstly, it conceals the unsightly screws that are typically used to attach the toilet seat or other bathroom components. This gives a more polished and seamless look to the overall bathroom decor. The cover is available in a variety of finishes and colors to match different bathroom styles, from modern and minimalist to classic and elegant. Secondly, the screw cover is an integral part of the damper mechanism, housing the internal components that provide the damping effect.
• This design innovation allows for easy installation and integration into existing toilet seat setups. It can be simply screwed in place of the regular screw, without the need for any major modifications or additional tools.

Plastic, Silicone Oil, and Rubber Damping Combination

• The use of plastic in the construction of the damper provides a lightweight and durable outer shell. It is resistant to moisture and corrosion, which is essential in the bathroom environment. The plastic also helps in maintaining the structural integrity of the damper, ensuring that it can withstand the repeated forces exerted during the opening and closing of the toilet seat.
• Silicone oil is a key component that offers a smooth and consistent damping effect. It provides the necessary viscosity to control the speed of the toilet seat's closing motion. The silicone oil is carefully calibrated to offer the right amount of resistance, preventing the seat from slamming shut and reducing noise. It also helps in protecting the toilet bowl and seat from damage due to sudden impacts.
• Rubber damping elements are incorporated to further enhance the buffering effect. The rubber provides additional elasticity and shock absorption, working in conjunction with the silicone oil to create a more comprehensive and reliable damping system. The combination of these materials ensures a soft and quiet closing of the toilet seat, enhancing the overall user experience.

Adjustable Damping Force

• The rotary damper allows for adjustable damping force. This feature is particularly useful as it can be customized to suit different toilet seat weights and user preferences. Lighter toilet seats may require a lower damping force for a more delicate closing, while heavier seats may need a stronger resistance to ensure a secure and smooth closure. The adjustable range provides flexibility in achieving the optimal balance between ease of use and safety.
• The adjustment mechanism is designed to be user-friendly and can be easily accessed and modified without the need for specialized tools or technical expertise.

Smooth and Quiet Operation

• The combination of the plastic, silicone oil, and rubber damping results in a remarkably smooth and quiet operation of the toilet seat. There are no jarring noises or sudden movements as the seat closes. This is especially beneficial in bathrooms where a peaceful and quiet environment is desired, such as in master bedrooms or in shared living spaces where noise can be a disturbance. The smooth operation also adds a touch of luxury and refinement to the overall bathroom experience.

Specification Details

• Model No.	Torque Range	Operation Angle	Minimum Working Angle	Use Temperature	Body Material	Rotary Shaft Material	Use Oil	Lifted Open Force	Life cycle
  HIE-T095C	30-60KGF.CM	0-110 °	30 °- 50 °	-5°-50°	PBT	PA66/ZINC ALLOY	Silicone oil	N/A	50000 time

Application Scenarios

• Ideal for use in residential bathrooms, where it not only improves the functionality of the toilet seat but also enhances the overall aesthetic appeal of the space. It is suitable for all types of toilet seats, whether they are standard, elongated, or designer models.
• Can also be used in commercial bathrooms in hotels, restaurants, and public facilities. The adjustable damping force and durable construction make it suitable for heavy-use environments, ensuring a consistent and pleasant user experience for all patrons.

Installation and Maintenance

• Installation: The installation process is straightforward. The decorative screw cover rotary damper is simply screwed in place of the existing toilet seat screws. Clear installation instructions are provided to guide users through the process, and no additional tools are usually required other than a screwdriver.
• Maintenance: Regular inspection of the damper for any signs of wear, such as leakage of silicone oil, cracks in the plastic or rubber components, or loose parts, is recommended. If any issues are detected, the damper can be easily replaced. Cleaning the damper with a mild detergent and a soft cloth is sufficient to keep it in good working condition.
