Precision Punches and dies, ISO 9861 type D punches HWS, HSS material optional ISO 6752

1,Quick Detail:

ISO 9861 type D punches, standard or special build upon customer drawing, applies in die stamping tooling.

2,Description:

ISO 9861-D punches / ISO9861 form D punches, standard or special punches, non-ejector punches, die inserts, die buttons, Ejector Pins, Core Pins etc. We provide precision tooling components with premium material and accurate precision.

3,Applications:

Our special order involves precision components of sheet metal stamping dies, Injection Moulds, press tooling, medical tooling.

4,Machine Specifications:

Wire EDM - 330*240*230mm
Sinker EDM - 450*300*320mm

CNC Lathe: Dia 1.0-320mm
CNC machininging center: 1100*600*500mm

Surface Grinding - 800*600*200mm
O.D. Grinding -Dia 0.2~200*600mm
I.D. Grinding –Dia 0.4~200*600mm

5,Feature Advantage:

• Especially strong tech staff capability of oval punches.

• Attractive cost and stable performance,
• Premium material, assured hardness, fast delivery
• Corrosion-resistance ,Easy installation,
• Laser etching mark available for easy Identification
• Custom made according to CAD.

6,Competitive Advantage:

• ISO 9861 form D punches MOQ 1pcs, HSS or HWS.
• Highly skilled engineering and technician work together, with rich experience to complete the special parts at attractive cost.
• Full procedure machineries in house, includes Wire EDM, Sinker EDM, CNC machining center, CNC lathe, Grinder, Polishing machines, offer comprehensive technique, assure the best quality and bring the cost down.
• One-stop services from raw material to fabrication and shipment delivery.
• Mature supply chain in industrial area, with rich experience on process control and professional quality control, the capacity is extendable.
• Good employee welfare keeps a stable and energetic technician team, which also help providing stable quality and in time delivery.

Q: If you make poor quality goods, will you refund?

A: We have very strict QC process, and each dimension and feature were measured honestly with QC signatures. Duplicated QC report is made, 1 send with delivery, and 1 kept by us. If there is any customer complaint, we can trace. If it is our issue, we will take our responsibility: refund or remake the parts.

Monthly capacity: 10000~30000pcs/month

Manufacturing facilities-Wire cut EDM, CNC lathe, CNC machining center, Sinker EDM:

Grinding facilities (including flat profile grinding and OD/ID cylinder grinding):

Quality inspection (CMM, Digital height gauge, projector, hardness meter):

How to order:
1.Send us CAD drawing or standard code.
2.Quotation will be offered within 1-2 workdays
3.Get agreement with price and terms,sign PO or Contract
4.Make payment and production starts.
5.Samples are available but maybe charged,depending on value and order quantity.

Tags: Punch and die, oval punches, Custom Punches, Precision punches and dies, Special Punches, Ejector punches, regular punches.
