Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Non-Standard High Precise Tooling Punching Parts as Drawings
Specifications
Brand Name :
Kingrui
Model Number :
KR011
Certification :
ISO9001: 2008
Place of Origin :
Guangdong, China ( Mainland)
MOQ :
1 pcs is available
Price :
Negotiable
Payment Terms :
T/ T, 50% as deposit before production , 50% before shipment
Supply Ability :
1200-1500 units per month
Delivery Time :
Normally, simple parts, 5-7 days, complicated parts, 7-15 days. According to QTY and the complexity of drawing.
Packaging Details :
PE film covered first, Plastic box, then carton last.
Name :
Non-Standard High Precise Tooling Punching Parts as Drawings
Processing Technology :
Grinding, Japan Sodick electric discharge machining and wedm
Material :
SKH57 or OEM as your need
Drawing software :
CAD, UG and Auto CAD or others
Drawings Format :
2D or 3D is ok
Tolerance :
0.002 mm or according to your request
Description

Non-Standard High Precise Tooling Punching Parts as Drawings

Part Introduction

The precision automotive parts described now, is a representative of our non-standard custom processes parts. Our company was founded more than 12 years, mainly provides processing services of non-standard precision mold parts, The processes of grinding and discharging, are the most adept technologies in our company.

Product Name

Non-Standard High Precise Tooling Punching Parts as Drawings
Choosed Material

DC53 was used for the precision part
Color

The color of the material itself or selectable according to customer's need
Machining Process

Main processes are grinding and electric discharge and wire EDM machining for this precision part
Tolerance

0.002 -0.005mm. Different processes have different precision requirements.
Application

Auto mold

Surface Treatment

This workpiece does not require any surface treatment, and if your processing parts are needed, we can offer the following: polishing, mirror polishing, PVD coating, DLC coating and so on.

Heat Treatment

Heat treatment, such as quenching and annealing, is based on the material and customer requirements

Machining Basis

 Primary cusromer's drawings, 2D or 3D is ok

Specification

A. Processing technology:

Surface grinding

CNC milling
Wire EDM

Electric discharge machining
Internal- external lapping processing

Punch forming and more

B. Packaging Details:

1. With plastic bag and plastic box, with PE film.
2. To be packed in cartons.
3. Use glues tape to seal cartons.
4. Deliver out by DHL, FEDEX, TNT, EMS and so on. Or according to your requirement.

C. Materials Supplied:

  • Stainless steel:SS304,SS303,SS316,SS204,
  • Aluminium: AL6061, AL6063, AL6005, AL7075, AL5052,
  • High- speed steel: CPMM4, KM-2, SKH51, M4, 1.2347,
  • Brass, copper, zinc, iron available in our factory
  • The examples listed above are only part of the material used. You can mark it on the drawings or in the mail.

D. Delivery time: Generally speaking, it needs 5- 15 working days and depends on your order quantity and complexity of your drawing design. Please tell us,if you are in urgent need.

E. Quality Assurance:

  • Strict control of material sources, and resolutely use material of customer demand for processing
  • Check all parts repeatedly
  • Each step in strict accordance with the ISO quality certification requirements
  • Send a quality report to you when the product is sent

Our advantage

A. More than 11 years precision auto parts, CNC milking machining, grinding machining and EDM machining experiences

B. We can produce diffuicult,high precision OEM parts

C. Reliable quality

D. Cost- effective,competitive price

E. Have its own processing plant, true, reliable, trustworthy
