Heavy Load Bearing Ball Thrust Bearing Steel Brass Nylon Cage
Heavy Load Bearing Ball Thrust Bearing Steel Brass Nylon Cage
Heavy Load Bearing Ball Thrust Bearing Steel Brass Nylon Cage
Heavy Load Bearing Ball Thrust Bearing Steel Brass Nylon Cage
Specifications
Brand Name :
UMT, NTN, NSK, FAG, INA, TIMKEN or OEM
Model Number :
51103
Certification :
ISO9001:2008, ISO/TS16949, REACH, ROHS, MSDS, CQC
Place of Origin :
Germany, France, Italy, Japan, Sweden, China etc.
MOQ :
10pieces
Price :
US$ 1 - 50 / piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
1,000,000 pieces per month
Delivery Time :
2-7 days after receiving the payments or deposit
Packaging Details :
original package, Netural package, single package, Wooden package+pallet, Carton package+pallet, or as customerized.
Type :
Ball
Structure :
Thrust ball
Number of Row :
Single row
Seals Type :
Z, ZZ, RS, 2RZ, 2RS,OPEN
Precision Rating :
ABEC-1/ P0, ABEC-3/P6, ABEC-5/P5, ABEC-7/P4
Material :
Chrome steel, Stainless steel
Cage :
Steel,Brass,Nylon
Clearance :
C2,C0,C3,C4,C5 etc.
Vibration :
V1,V2,V3
Service :
OEM&ODM both available
Sample available :
Yes
Manufacturer :
Yes
ID :
17
OD :
30
Width :
9
Description

Brand thrust ball bearing 51103 all type of bearing can supply

Thrust ball bearing is a kind of separation type bearings, shaft circle, seat ring may and maintain shelf, steel ball component separated. Shaft with circle is Axis collar, seat combined with circle is combined bearing hole between the collar, and axis; a gap.

Speed is low, i.e.one-way thrust ball bearings can restrict axis and the shell of a direction axial displacement, two-way bearing can limit
Making the axial displacement of two directions.


Brand thrust ball bearing 51103 all type of bearing can supply
Model Number 51103 Thrust ball bearing
Structure Thrust ball
Type Ball
Inside Diameter 17mm
Outside Diameter 30mm
Width 9mm
Net weight 0.028kg
Seals Type Z, ZZ, RS, 2RZ, 2RS,OPEN
Number of Row Single Row
Material Chrome steel, Stainless steel
Cage Brass, Steel, Nylon
Vibration Level V1, V2, V3
Clearance C2, C0, C3, C4, C5 etc.
Precision Rating P0, P6, P5, P4, P2
Hardness 59-63HRC
Service OEM&ODM both available
Sample available Yes
Manufacturer Yes
Quality guaranteed Yes
Certificate ISO9001:2008, ISO/TS16949
Application/Function Automotive, truck, tractors, construction machinery, Electric Tools, Sports Apparatus, Office equipment, Medical devices, Defense, Nuclear, Electric Power Generation, Wind Energy, Robotics, Medical & Dental, Agriculture, Food Processing etc.
Other Service Design service, Buyer label service
Packaging Details Industrial Packing, Individual Boxed Packing, or OEM
Delivery Detail 2-7 days after receiving the payments or deposit

Series

N0. OLD NO. mm mm mm Dynamic Static Grease Oil Kg/pcs
Cr Cor r/min r/min
51100 8100 10 24 9 10 14 6500 10000 0.02
51101 8101 12 26 9 10.3 15.4 6500 10000 0.022
51102 8102 15 28 9 10.5 16.8 6100 9400 0.024
51103 8103 17 30 9 10.8 18.2 6100 9400 0.028
51104 8104 20 35 10 14.2 24.7 5100 7900 0.04
51105 8105 25 42 11 19.5 37.2 4400 6800 0.059
51106 8106 30 47 11 20.4 42.2 4300 6600 0.068
51107 8107 35 52 12 20.4 44.7 3900 6000 0.09
51108 8108 40 60 13 26.9 62.8 3400 5300 0.12
51109 8109 45 65 14 27.8 69.1 3200 5000 0.15
51110 8110 50 70 14 28.8 75.4 3100 4800 0.16
511111 - 55 78 16 — — — — 0.24
51112 8112 60 85 17 41.4 113 2600 4000 0.29
51113 8113 65 90 17 41.7 117 2400 3700 0.34
51114 8114 70 95 18 43 127 2300 3600 0.36
51115 8115 75 100 19 42.3 127 2200 3400 0.42
51116 8116 80 105 19 44.6 141 2100 3300 0.43
51117 8117 85 110 19 45.9 150 2100 3200 0.46
51118 8118 90 120 22 59.7 190 1900 2900 0.68
51120 8120 100 135 25 85 268 1600 2500 0.99
51122 8122 110 145 25 87.1 288 1600 2400 1.08
51124 8124 120 155 25 89 308 1500 2300 1.16

N0. OLD NO. mm mm mm Dynamic Static Grease Oil Kg/pcs
Cr Cor r/min r/min
51209 8209 45 73 20 47.7 105 2600 4000 0.32
51210 8210 50 78 22 48.5 111 2300 3600 0.39
51211 8211 55 90 25 69.4 159 2100 3200 0.61
51212 8212 60 95 26 73.6 179 1900 3000 0.69
51213 8213 65 100 27 74.8 189 1900 2900 0.77
51214 8214 70 105 27 73.6 189 1800 2800 0.81
51215 8215 75 110 27 77.4 209 1800 2700 0.86
51216 8216 80 115 28 78.5 218 1700 2600 0.95
51217 8217 85 125 31 92.3 251 1500 2300 1.29
51218 8218 90 135 35 117 326 1400 2100 1.77
51219 - 95 140 40 — — — — 2.2
51220 8220 100 150 38 147 410 1200 1900 2.36
51222 8222 110 160 38 148 431 1200 1800 2.57
51224 8224 120 170 39 154 472 1100 1700 2.86
51226 8226 130 190 45 203 622 970 1500 4.09
51228 8228 140 200 46 215 669 940 1450 4.46
51230 8230 150 215 50 244 768 840 1300 5.64
51232 8232 160 225 51 247 803 810 1250 6.53
51234 8234 170 240 55 269 874 750 1150 8.12
51236 806 180 250 56 294 986 710 1100 8.68
51238 8238 190 270 62 298 1010 650 1000 11.7
51240 8240 200 280 62 314 1110 620 950 12.2

Our other main products:
Deep groove ball bearing, Taper roller bearing, Ceramic ball bearing, Cylindrical roller bearing, Spherical roller bearing, Self-aligning bearing, Adapter sleeve, Angular contact ball bearing, Thrust ball bearing, Thrust roller bearing, Needle roller bearing, Spherical plain bearings, Linear bearing, Whell hub bearing, Special bearing

Company Information

Shenzhen Youmeite Berings CO., ltd is branch company of shandong UMT bearing corporation responsible for oversea marketing. Our plant shandong UMT has been working in the filed of bearing design and manufacturing for more than 10years now is taking a leading position in mainland china. Our plant has more than 500 employees , including 30 bearing professional techincians; more than 600 new bearing items can be completed each year. we can produce all kinds of bearing as customer's requirement.

Company: Shenzhen Youmeite Bearings Co., Ltd
Name: CANDY AO
Web: www.umtbearing.com
Tel: 0086-755-23300976
Fax: 0086-755-28142811
Skype candy_umt
Email: sales005@umtbearing.com
