Sealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / Motor
Sealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / Motor
Sealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / Motor
Sealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / Motor
Specifications
Brand Name :
UMT, NTN, NSK, FAG, INA, TIMKEN or OEM
Model Number :
6202
Certification :
ISO9001:2008, ISO/TS16949, REACH, ROHS, MSDS, CQC
Place of Origin :
Germany, France, Italy, Japan, Sweden, China etc.
MOQ :
10pieces
Price :
US$ 1 - 50 / piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
1,000,000 pieces per month
Delivery Time :
2-7 days after receiving the payments or deposit
Packaging Details :
original package, Netural package, single package, Wooden package+pallet, Carton package+pallet, or as customerized.
Type :
Ball bearing
Structure :
deep groov
Number of Row :
Single row
Seals Type :
Z, ZZ, RS, 2RZ, 2RS,OPEN
Precision Rating :
ABEC-1/ P0, ABEC-3/P6, ABEC-5/P5, ABEC-7/P4
Material :
Chrome steel, Stainless steel
Cage :
Steel,Brass,Nylon
Clearance :
C2,C0,C3,C4,C5 etc.
Vibration :
V1,V2,V3
Service :
OEM&ODM both available
Sample available :
Yes
Manufacturer :
Yes
ID :
15mm
OD :
35mm
Width :
11mm
Description

Sealed Chrome steel 6202 zz 2rs deep groove ball bearing for fan / motor

Description:

Deep Groove Ball Bearing are the most widely used roller bearing type in the world due to their

versatility and overall performance. They are characterized by having deep raceway grooves in

which the inner and outer rings have circular arcs of slightly larger radius than that of the balls.

Applications:

The deep groove ball bearing can be used in many different places such as:

Gearbox, instruments and meters, electric motor, electric appliance, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, construction machinery, and so on.

Deep groove ball bearings are the most widely used bearing type. Consequently, they are available from in many designs, variants, series and sizes.

The deep groove ball bearing have 6000 series ,6200series, 6300series , 6400 series ,

16000 series 62200 series ,62300 series ,61700 series 61800 series 61900 series .

Sealed Chrome steel 6202 zz 2rs deep groove ball bearing for fan / motor
Model Number 6205zz
Structure deep groove
Type ball bearing
ID 15mm
OD 35mm
Width 11mm
Seals Type Z, ZZ, RS, 2RZ, 2RS,OPEN
Number of Row Single Row
Material Chrome steel, Stainless steel
Cage Brass, Steel, Nylon
Vibration Level V1, V2, V3
Clearance C2, C0, C3, C4, C5 etc.
Precision Rating P0, P6, P5, P4, P2
Hardness 59-63HRC
Service OEM&ODM both available
Sample available Yes
Manufacturer Yes
Quality guaranteed Yes
Certificate ISO9001:2008, ISO/TS16949
Application/Function Steel Industry, Mining&Construction, Paper making Machinery,vibrating screens, shakers, conveyors
Other Service Design service, Buyer label service
Packaging Details Industrial Packing, Individual Boxed Packing, or OEM
Delivery Detail 2-7 days after receiving the payments or deposit

Other styles:

N0. OLD NO. mm mm mm Dynamic Static Grease Oil Kg/pcs
Cr Cor r/min r/min
16004 7000104 20 42 8 7.9 4.5 16000 19000 0.05
6004 104 20 42 12 9.38 5.02 16000 19000 0.069
6204 204 20 47 14 12.8 6.65 14000 18000 0.106
6304 304 20 52 15 15.8 7.88 13000 16000 0.142
6404 404 20 72 19 31 15.2 9500 13000 0.4
61805 1000805 25 37 7 4.3 2.9 16000 20000 0.022
61905 1000905 25 42 9 7 4.55 16000 19000 0.041
16005 7000105 25 47 8 8.85 5.6 15000 18000 0.06
6005 105 25 47 12 10.1 5.85 15000 18000 0.08
6205 205 25 52 15 14 7.85 13000 15000 0.128
6305 305 25 62 17 20.6 11.3 11000 13000 0.232
6405 405 25 80 21 36.1 19.4 9100 11000 0.53
61806 1000806 30 42 7 4.55 3.4 15000 18000 0.026
61906 1000906 30 47 9 7.25 5 14000 17000 0.045
16006 7000106 30 55 9 11.2 7.35 13000 15000 0.085
6006 106 30 55 13 13.2 8.25 13000 15000 0.116
6206 206 30 62 16 19.5 11.3 11000 13000 0.199
6306 306 30 72 19 26.7 15 6600 12000 0.346
6406 406 30 90 23 43.4 23.9 8100 9700 0.735
61807 1000807 35 47 7 4.75 3.85 13000 19000 0.03
61907 1000907 35 55 10 10.9 7.75 12000 14000 0.073
16007 7000107 35 62 9 12.2 8.85 11000 13000 0.11
N0. OLD NO. mm mm mm Dynamic Static Grease Oil Kg/pcs
Cr Cor r/min r/min
6007 107 35 62 14 15.9 10.3 11000 13000 0.155
6207 207 35 72 17 25.7 15.4 9200 11000 0.288
6307 307 35 80 21 33.4 19.3 8500 10000 0.457
6407 407 35 100 25 55 31 7200 8600 0.952
61808 1000808 40 52 7 4.95 4.2 12000 14000 0.033
61908 1000908 40 62 12 13.7 9.95 11000 13000 0.112
16008 7000108 40 68 9 12.6 9.6 9000 11000 0.125
6008 108 40 68 15 17 11.8 9000 11000 0.185
6208 208 40 80 18 29.5 18 8000 10000 0.368
6308 308 40 90 23 40.8 24 7000 8500 0.639
6408 408 40 110 27 65.5 37.5 6300 8000 1.221
61809 1000809 45 58 7 6.4 5.6 9000 12000 0.03
61909 1000909 45 68 12 14.1 10.9 8500 11000 0.123
16009 7000109 45 75 10 15.6 12.2 8000 10000 0.155
6009 109 45 75 16 21 14.8 8000 10000 0.23
6209 209 45 85 19 31.5 20.5 7000 9000 0.416
6309 309 45 100 25 52.8 31.8 6300 7500 0.837
6409 409 45 120 29 77.5 45.5 5600 7000 1.52
6022 122 110 170 28 81.8 72.8 3400 4300 1.89
61810 1000810 50 65 7 6.6 6.1 8500 10000 0.043
61910 1000910 50 72 12 14.5 11.7 8000 9500 0.122
16010 7000110 50 80 10 16.1 13.1 8000 9500 0.166

N0. OLD NO. mm mm mm Dynamic Static Grease Oil Kg/pcs
Cr Cor r/min r/min
6010 110 50 80 16 22 16.2 7000 9000 0.25
6210 210 50 90 20 35 23.2 6700 8500 0.463
6310 310 50 110 27 61.8 38 6000 7000 1.082
6410 410 50 130 31 922 55.2 5300 6300 1.855
61811 1000811 55 72 9 9.1 8.4 8000 9500 0.07
61911 1000911 55 80 13 15.9 13.2 7500 9000 0.17
16011 7000111 55 90 11 19.4 16.2 7000 8500 0.207
6011 111 55 90 18 30.2 21.8 7000 8500 0.362
6211 211 55 100 21 43.2 29.2 6000 7500 0.603
6311 311 55 120 29 71.5 44.8 5600 6700 1.367
6411 411 55 140 33 100 62.5 4800 6000 2.316
61812 1000812 60 78 10 9.1 8.7 7000 8500 0.093
61912 1000912 60 85 13 16.4 14.2 6700 8000 0.181
16012 7000112 60 95 11 19.9 17.5 6300 7500 0.224
6012 112 60 95 18 31.5 24.2 6300 7500 0.385
6212 212 60 110 22 47.8 32.8 5600 7000 0.789
6312 312 60 130 31 81.8 51.8 5000 6000 1.71
6412 412 60 150 35 109 70 4500 5600 2.811
61813 1000813 65 85 10 11.9 11.5 6700 8000 0.13
61913 1000913 60 90 13 17.4 16 6300 7500 0.196
16013 7000113 60 100 11 20.5 18.6 6000 7000 0.241
6013 113 65 100 18 32 24.8 6000 7000 0.41

Sealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / MotorSealed Chrome Steel 6202 Zz 2rs Deep Groove Ball Bearings For Fan / Motor

Our other main products:
Deep groove ball bearing, Taper roller bearing, Ceramic ball bearing, Cylindrical roller bearing, Spherical roller bearing, Self-aligning bearing, Adapter sleeve, Angular contact ball bearing, Thrust ball bearing, Thrust roller bearing, Needle roller bearing, Spherical plain bearings, Linear bearing, Whell hub bearing, Special bearing
