High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook
Specifications
Brand Name :
TIMKEN
Model Number :
53222
MOQ :
1pc
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000pc per month
Delivery Time :
16 days
Packaging Details :
Usually carton packaging, or PVC bag with a label. Specifically according to the customer to your needs, you can use any packaging situation
Structure: :
Thrust
Model Number: :
53222
Precision Rating: :
ABEC1 3 5 7 9
Type: :
Ball,thrust ball bearing
Seals Type: :
OPEN
Brand Name: :
TIMKEN
Bore Size: :
110 mm
Number of Row: :
Single Row
Outside Diameter: :
160 mm
Material: :
bearing steel chrome steel Gcr15
Cage: :
steel carbon steel brass
Thickness: :
67mm
Hardness: :
HRC60-65
Application: :
Crane hook,vertical pumps,
Description

High loads TIMKEN wheel bearing chrome steel Gcr15 For Crane hook

Specifications

TIMKEN wheel bearing 53222
1.Gcr15 material
2.High loads
3.Separated type
4.ISO:9001:2000

TIMKEN wheel bearing 53222 bearing thrust ball bearing

Descriptions of TIMKEN wheel bearing 53222

Thrust bearings are designed to handle axial loads while operating at high speed. Bearings are composed of bearing rings with raceway grooves for the balls. Double direction thrust ball bearings can support axial load in both directions. Neither style can be subjected to radial loads. Available in bore dimension range from 10mm to 560mm.

Thrust ball bearings consist of shaft washer, a housing washer and a ball and cage thrust assembly. They are separable which means that mounting is simple. They can accommodate axial loads in one direction only and must not be subjected to any radial load.

Thrust ball bearings are classified into those with flat seats or aligning seats depending on the shape of the outer ring seat (housing washer). They can sustain axial loads but no radial loads. For Single-Direction Thrust Ball Bearings, pressed steel cages and machined brass cages are usually used The cages in Double- Direction Thrust Ball Bearings are the same as those in Single-Direction Thrust Ball Bearings of the same diameter series.

Single direction thrust ball bearings consist of a shaft washer, a housing washer and a ball and cage assembly. These bearings can only handle thrust loads in one direction.

Double direction thrust ball bearings consist of two housing washers, two ball and cage assemblies and one shaft washer. These bearings can handle thrust loads from two directions.

1. Thrust ball bearing can handle loads in the axial direction only.
2. Bearing rings mounted on the shaft are called shaft washers, while those mounted in the housing are called housing washers.
3. Both washers contain raceways for the balls.
4. Thrust ball bearings are available as both single an bi-directional types. The bi-directional thrust bearing incorporates a third washer and an additional set of balls.
5. The center washer is located in axial direction by a shaft shoulder and sleeve.
6. Care must be taken in handling to prevent damage to separate rings and ball assemblies.
7. The thrust ball bearings are Available in two designs: single direction and double direction.
8. Material: bearing steel, high chrome, carbon steel, stainless steel, ect.

Type of thrust ball bearing

1. Single way thrust ball bearing

2. Double way thrust ball bearing

3. Flat thrust ball bearing

Application

Crane hook, vertical pumps, vertical centrifugal,

lifting jack,

low speed reducer,

Component

Seat, shaft ring and ball cage

Single way thrust ball bearing

Seat, shaft ring and ball cage, separate

Cage: pressed steel, Injection of glass fiber

reinforced

nylon 6.

1.One-piece machine cutting brass cage

2.One-piece machine cutting copper steel cage

3.Modular machine cutting brass cage

Flat thrust ball bearing

Low speed, long life

Application:1.the elevator parts/plastic machinery

2.office equipment/medical apparatus and

instruments

3.Stepper motor/deceleration speed change device

4.Pressure rotor/fitness and sports equipment
